KMC Controls SSS-1013 Sensor
The KMC Controls SSS-1013 Sensor is a high-precision differential pressure flow sensor designed for demanding VAV terminal unit and fan-powered box applications. Featuring an insertion length of 5-13/32 inches, this probe is specifically engineered to provide accurate velocity pressure readings in main or branch duct systems. Unlike the SSS-1000 series, the SSS-1013 features 3/16-inch fittings designed for direct connection to 1/4-inch OD polyethylene tubing, eliminating the need for barb union adapters and simplifying the installation for field technicians. With dual sensing points, it ensures a reliable average velocity measurement essential for building automation systems (BAS) and precise individual zone control. The integral flange with gasket ensures a leak-proof seal against the ductwork, maintaining the integrity of the HVAC airflow measurement even in high-velocity environments ranging from 200 to 6,000 FPM. This probe is fully compatible with KMC?ÇÖs CSP-5000, KMD-7000, and BAC-7000 series controllers, providing the granular data needed for energy-efficient air volume management.
Key Benefits for Technicians:
- Simplified Integration: Direct 1/4" OD tubing connection reduces leak points and speeds up commissioning by bypassing the need for 3/8" to 1/4" adapters.
- Versatile Mounting: The differential pressure sensing tubes can be rotated 90 degrees to measure static pressure, offering flexibility for various air flow station configurations.
- Enhanced Accuracy: Features dual sensing points to capture a better representative sample of duct air velocity compared to single-point pitot tubes.
- Durable Construction: Manufactured with UL94-5V rated ABS/polycarbonate material, suitable for operating environments between 40??F and 120??F.
Common Questions & Answers:
What duct sizes is the SSS-1013 compatible with?
With its 5-13/32" length, this sensor is optimized for terminal box inlet diameters and ducts ranging from 6 to 8 inches to ensure the sensing points are positioned correctly within the air stream.
Does this require a specific orientation during installation?
Yes. For differential pressure, the "FLOW" arrow must point in the direction of the airflow. For static pressure measurements, the probe should be mounted perpendicular to the flow.
Can I use this with non-KMC VAV controllers?
Yes, the KMC SSS-1013 is a standard pneumatic-to-electronic sensing interface that works with any controller capable of translating differential pressure into CFM based on the sensor's K-factor.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
