Veris Industries X100CHB Breaker
Integrate the Veris Industries X100CHB into your next building automation or HVAC control project for a reliable, multi-tap power solution. This 100VA control transformer is engineered for versatile field applications, featuring a primary input that supports 120/208/240/480 VAC to deliver a consistent 24 VAC output. Designed specifically for the rigors of industrial environments, the X100CHB breaker transformer includes an integrated, manually resettable circuit breaker to protect downstream 24V components from overcurrent and short-circuit conditions. The hardware is built for flexible installation, utilizing a dual threaded hub and foot-mount design that simplifies integration into existing panels or electrical boxes. Whether you are powering BAS controllers, driving high-draw relays, or supplying electrical current to sensitive HVAC sensors, this Class 2 UL-listed transformer ensures your control circuits remain stabilized and protected. The color-coded lead wires and robust Veris X-series construction reduce installation time for contractors while maintaining high performance across a wide operating temperature range of -40° to 149°F.
Key Benefits
- Multi-Tap Input Versatility: Supports 120V, 208V, 240V, and 480V primary voltages, reducing the number of individual parts required for diverse site specifications.
- Integrated Circuit Protection: Features a built-in circuit breaker for superior overcurrent protection, eliminating the need for external fusing for the control circuit.
- Flexible Mounting Options: Equipped with dual threaded hubs and a flanged foot mount to accommodate various conduit and enclosure configurations.
- High Power Capacity: Provides 100VA (99VA) of power, making it ideal for large-scale building automation systems and demanding relay applications.
- Industrial-Grade Reliability: UL and CE certified for safe operation in commercial HVACR environments, ensuring consistent 24VAC control power.
Common Questions
What is the primary benefit of the dual hub design on the X100CHB?
The dual threaded hub allows for much cleaner wire management and conduit connection. One hub can be dedicated to high-voltage primary lines while the other manages the 24V secondary output, maintaining separation and meeting code requirements more easily in tight spaces.
Can the circuit breaker be reset if it trips?
Yes, the Veris X100CHB features a manually resettable breaker. If an overcurrent event occurs on the secondary side, the breaker trips to protect the transformer. Once the fault is cleared, you can simply press the reset button to restore power without replacing fuses.
Is this transformer suitable for outdoor installations?
While the unit has a wide operating temperature range from -40° to 149°F, it is a closed transformer designed for use within a protected electrical enclosure or BAS panel. It should not be directly exposed to rain or moisture without a NEMA-rated housing.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
Original: $33.91
-65%$33.91
$11.87Veris Industries X100CHB Breaker
Integrate the Veris Industries X100CHB into your next building automation or HVAC control project for a reliable, multi-tap power solution. This 100VA control transformer is engineered for versatile field applications, featuring a primary input that supports 120/208/240/480 VAC to deliver a consistent 24 VAC output. Designed specifically for the rigors of industrial environments, the X100CHB breaker transformer includes an integrated, manually resettable circuit breaker to protect downstream 24V components from overcurrent and short-circuit conditions. The hardware is built for flexible installation, utilizing a dual threaded hub and foot-mount design that simplifies integration into existing panels or electrical boxes. Whether you are powering BAS controllers, driving high-draw relays, or supplying electrical current to sensitive HVAC sensors, this Class 2 UL-listed transformer ensures your control circuits remain stabilized and protected. The color-coded lead wires and robust Veris X-series construction reduce installation time for contractors while maintaining high performance across a wide operating temperature range of -40° to 149°F.
Key Benefits
- Multi-Tap Input Versatility: Supports 120V, 208V, 240V, and 480V primary voltages, reducing the number of individual parts required for diverse site specifications.
- Integrated Circuit Protection: Features a built-in circuit breaker for superior overcurrent protection, eliminating the need for external fusing for the control circuit.
- Flexible Mounting Options: Equipped with dual threaded hubs and a flanged foot mount to accommodate various conduit and enclosure configurations.
- High Power Capacity: Provides 100VA (99VA) of power, making it ideal for large-scale building automation systems and demanding relay applications.
- Industrial-Grade Reliability: UL and CE certified for safe operation in commercial HVACR environments, ensuring consistent 24VAC control power.
Common Questions
What is the primary benefit of the dual hub design on the X100CHB?
The dual threaded hub allows for much cleaner wire management and conduit connection. One hub can be dedicated to high-voltage primary lines while the other manages the 24V secondary output, maintaining separation and meeting code requirements more easily in tight spaces.
Can the circuit breaker be reset if it trips?
Yes, the Veris X100CHB features a manually resettable breaker. If an overcurrent event occurs on the secondary side, the breaker trips to protect the transformer. Once the fault is cleared, you can simply press the reset button to restore power without replacing fuses.
Is this transformer suitable for outdoor installations?
While the unit has a wide operating temperature range from -40° to 149°F, it is a closed transformer designed for use within a protected electrical enclosure or BAS panel. It should not be directly exposed to rain or moisture without a NEMA-rated housing.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
