Resideo V4044A1001 Zone Valve
The Resideo V4044A1001 is a robust 120Vac three-way diverting zone valve designed for hydronic systems requiring precise flow control between two different circuits. Engineered with a 1/2-inch flare connection and a 4.0 Cv flow coefficient, this unit effectively manages fluid temperatures ranging from 40°F to 200°F. The construction features a durable brass body, a stainless steel stem, and EPDM rubber packing O-rings to ensure long-term seal integrity. With a 20 PSI maximum close-off pressure, the valve utilizes a spring return to Port A mechanism, maintaining Port A in a normally closed position during power loss. The inclusion of a manual opener allows for system filling and emergency operation without electrical actuation. This diverting valve is essential for bypass applications or domestic hot water priority setups in modern boiler loops, utilizing 18-inch electrical leads for straightforward field wiring.
Key Technical Benefits- Diverting Flow Control: Specifically engineered for diverting applications, routing flow from a common inlet to two separate outlets.
- High-Temperature Resilience: Sustains performance in systems with fluid temperatures up to 200°F, ideal for high-mass radiation and baseboard heating.
- Industrial-Grade Sealing: Features a Buna-N rubber ball plug and brass seating to prevent cross-port leakage.
- Manual Override: Integrated lever allows for manual operation during commissioning or power failures.
- Reliable Actuation: The 120V motor provides consistent torque for reliable cycling in high-demand residential and light commercial environments.
Can this valve be used for mixing applications?
No, the V4044A1001 is a diverting valve designed to split flow from one inlet into two outlets. For mixing two inlets into one outlet, a dedicated mixing valve is required to prevent premature motor failure and water hammer.
What is the purpose of the manual lever?
The manual lever allows the technician to manually open the valve to Port A for system draining, filling, or troubleshooting when the 120V actuator is de-energized.
Is the actuator head replaceable without draining the system?
Yes, the motorized head can be serviced or replaced without breaking the plumbing line, reducing downtime during field repairs.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
Original: $147.11
-65%$147.11
$51.49Resideo V4044A1001 Zone Valve
The Resideo V4044A1001 is a robust 120Vac three-way diverting zone valve designed for hydronic systems requiring precise flow control between two different circuits. Engineered with a 1/2-inch flare connection and a 4.0 Cv flow coefficient, this unit effectively manages fluid temperatures ranging from 40°F to 200°F. The construction features a durable brass body, a stainless steel stem, and EPDM rubber packing O-rings to ensure long-term seal integrity. With a 20 PSI maximum close-off pressure, the valve utilizes a spring return to Port A mechanism, maintaining Port A in a normally closed position during power loss. The inclusion of a manual opener allows for system filling and emergency operation without electrical actuation. This diverting valve is essential for bypass applications or domestic hot water priority setups in modern boiler loops, utilizing 18-inch electrical leads for straightforward field wiring.
Key Technical Benefits- Diverting Flow Control: Specifically engineered for diverting applications, routing flow from a common inlet to two separate outlets.
- High-Temperature Resilience: Sustains performance in systems with fluid temperatures up to 200°F, ideal for high-mass radiation and baseboard heating.
- Industrial-Grade Sealing: Features a Buna-N rubber ball plug and brass seating to prevent cross-port leakage.
- Manual Override: Integrated lever allows for manual operation during commissioning or power failures.
- Reliable Actuation: The 120V motor provides consistent torque for reliable cycling in high-demand residential and light commercial environments.
Can this valve be used for mixing applications?
No, the V4044A1001 is a diverting valve designed to split flow from one inlet into two outlets. For mixing two inlets into one outlet, a dedicated mixing valve is required to prevent premature motor failure and water hammer.
What is the purpose of the manual lever?
The manual lever allows the technician to manually open the valve to Port A for system draining, filling, or troubleshooting when the 120V actuator is de-energized.
Is the actuator head replaceable without draining the system?
Yes, the motorized head can be serviced or replaced without breaking the plumbing line, reducing downtime during field repairs.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
