Resideo V110D1008 Body
For high-capacity hydronic and steam applications, the Resideo V110D1008 straight-pattern valve body provides the robust flow control required by North American two-pipe systems. This 3/4 inch NPT radiator valve body is engineered with a high 5.8 Cv flow coefficient, making it a reliable choice for free-standing radiators and convectors that demand higher heat outputs. The nickel-plated bronze construction ensures long-term durability against corrosion and mineral buildup, common in closed-loop systems.
Specifically designed for seamless integration with T104 thermostatic actuators, the V110D1008 allows for precise zone modulation without the need for external power. The valve features a resilient EPDM seat disc for bubble-tight shutoff on both hot water (up to 150 psi) and low-pressure steam (up to 15 psi). Field service is streamlined via the replaceable cartridge design; using the MT110C1011 service tool, technicians can swap internal components while the valve remains in-line and under pressure, significantly reducing system downtime.
- High Capacity Performance: Delivering 5.8 Cv and up to 162,000 BTU/hr for steam applications.
- Ease of Maintenance: Internal working parts are accessible via a cartridge insert for rapid in-service repair.
- Superior Materials: Formulated with nickel-plated bronze and an EPDM disc for reliable 240°F maximum operating temperatures.
- System Compatibility: Meets ASHRAE Standard 102-1989 for non-electric thermostatic radiator valves.
Is this valve body compatible with standard non-Resideo actuators?
The V110D1008 is specifically machined for the T104 series actuators. While similar in appearance to some European patterns, the stroke and thread pitch are optimized for the T104 to ensure accurate temperature modulation.
Can the cartridge be replaced without draining the system?
Yes, when used with the MT110C1011 change-out tool, the internal cartridge can be serviced while the system is live, which is a major advantage for commercial property maintenance.
Does this work for both one-pipe and two-pipe steam?
This valve is intended for two-pipe steam or hot water systems. It is not suitable for one-pipe steam systems as it does not allow for the necessary condensate drainage through the valve body.
This item is not eligible for free shipping.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
