Resideo TH114-AF-024T Thermostat
The Resideo TH114-AF-024T is a specialized 24 Vac non-programmable thermostat engineered for high-performance electric floor heating and ambient air temperature control. Developed for professional contractors, this unit features three distinct operational modes: A mode for ambient air Control, F mode for dedicated floor temperature regulation via the included Aube AC112-01 sensor, and AF mode for combined ambient control with adjustable floor limits. This versatility ensures the unit maintains tight 0.9 degree accuracy while preventing subfloor overheating. Designed for vertical mounting, the TH114-AF-024T utilizes external electromechanical relay switching to handle standard 24V signal requirements, making it an ideal choice for large-scale radiant heating projects where multi-zone synchronization is critical. The backlit interface and intuitive up/down interface provide high-visibility feedback and consistent 1-degree differential performance, ensuring reliable floor heat regulation in a slim, contemporary white housing.
Key Benefits for Technicians- Dual-Mode Versatility: Supports Floor (F), Ambient (A), and Ambient with Floor limits (AF) for tailored system design.
- High-Precision Control: Maintains 0.9°F accuracy with a 1-degree differential to eliminate temperature swings in radiant systems.
- Sensor-Driven Protection: Ships with a 15-foot Aube AC112-01 floor sensor to monitor subfloor temperatures and protect delicate flooring materials.
- Reliable Switching: Utilizes a 24Vac signal to trigger external electromechanical relays, allowing for flexible load management on large circuits.
- Pro-Grade Interface: Features a clear backlit display and an ON/STANDBY switch for seasonal shutdown without losing configuration settings.
How do I switch between Celsius and Fahrenheit on the TH114-AF-024T?
The unit features internal DIP switches on the back of the faceplate that allow you to toggle temperature units and operational modes (A/AF/F) during installation.
Can this thermostat directly power an electric heating cable?
No, this is a low-voltage (24 Vac) model. It requires an external electromechanical relay or power base to switch the high-voltage load of the heating elements.
What happens if the floor sensor is disconnected?
If the sensor is damaged or disconnected while in F or AF mode, the thermostat will display an "Er" code; however, it can be reconfigured to A mode for ambient-only control if a sensor cannot be run.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
Original: $147.78
-65%$147.78
$51.72Resideo TH114-AF-024T Thermostat
The Resideo TH114-AF-024T is a specialized 24 Vac non-programmable thermostat engineered for high-performance electric floor heating and ambient air temperature control. Developed for professional contractors, this unit features three distinct operational modes: A mode for ambient air Control, F mode for dedicated floor temperature regulation via the included Aube AC112-01 sensor, and AF mode for combined ambient control with adjustable floor limits. This versatility ensures the unit maintains tight 0.9 degree accuracy while preventing subfloor overheating. Designed for vertical mounting, the TH114-AF-024T utilizes external electromechanical relay switching to handle standard 24V signal requirements, making it an ideal choice for large-scale radiant heating projects where multi-zone synchronization is critical. The backlit interface and intuitive up/down interface provide high-visibility feedback and consistent 1-degree differential performance, ensuring reliable floor heat regulation in a slim, contemporary white housing.
Key Benefits for Technicians- Dual-Mode Versatility: Supports Floor (F), Ambient (A), and Ambient with Floor limits (AF) for tailored system design.
- High-Precision Control: Maintains 0.9°F accuracy with a 1-degree differential to eliminate temperature swings in radiant systems.
- Sensor-Driven Protection: Ships with a 15-foot Aube AC112-01 floor sensor to monitor subfloor temperatures and protect delicate flooring materials.
- Reliable Switching: Utilizes a 24Vac signal to trigger external electromechanical relays, allowing for flexible load management on large circuits.
- Pro-Grade Interface: Features a clear backlit display and an ON/STANDBY switch for seasonal shutdown without losing configuration settings.
How do I switch between Celsius and Fahrenheit on the TH114-AF-024T?
The unit features internal DIP switches on the back of the faceplate that allow you to toggle temperature units and operational modes (A/AF/F) during installation.
Can this thermostat directly power an electric heating cable?
No, this is a low-voltage (24 Vac) model. It requires an external electromechanical relay or power base to switch the high-voltage load of the heating elements.
What happens if the floor sensor is disconnected?
If the sensor is damaged or disconnected while in F or AF mode, the thermostat will display an "Er" code; however, it can be reconfigured to A mode for ambient-only control if a sensor cannot be run.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
