Resideo FC40R1102 Filter
For service technicians and building managers seeking a high-efficiency alternative to restrictive 1-inch filters, the Resideo FC40R1102 delivers a professional-grade filtration solution. This 14x14x4 MERV 10 return grille filter is engineered with a deep-pleated media design that provides significantly more surface area than standard glass-fiber or pleated 1-inch inserts. By utilizing 4-inch deep media within a frame that fits most standard return grilles, the FC40R1102 effectively captures mold spores, pollen, and dust without sacrificing system performance. With a static pressure drop of only 0.12 in. w.c. at 300 FPM and a maximum airflow capacity of 500 CFM, this media air cleaner maintains optimal velocity across the heat exchanger, protecting coils from fouling and ensuring your blower motor operates within its specific curves. For high-performance HVAC maintenance, replacing standard filters with this pleated media filter reduces pressure drop issues common in high-MERV 1-inch applications.
Key Benefits
- Reduced Pressure Drop: Designed with a low 0.12 in. w.c. static resistance at 300 FPM to prevent cavitation and excessive blower wear.
- High Dust Holding Capacity: Deep-pleated media offers increased surface area, extending the service interval compared to standard 1-inch filters.
- Enhanced IAQ Performance: MERV 10 rating ensures effective capture of airborne particles without the airflow restriction typically seen in high-MERV thin filters.
- Universal Compatibility: Specifically designed to fit most return filter grilles that accept standard 14x14 nominal sizes.
Common Questions
Can I use this 4-inch filter in a standard 1-inch return grille?
Yes, the Resideo FC40R1102 is specifically engineered to fit within the frame of most third-party return grilles, allowing the 4-inch deep media to extend into the duct transition while maintaining a flush appearance at the face.
How does this filter impact my system's static pressure?
The FC40R1102 is designed for low resistance. With a .12 at 300 FPM drop, it typically offers better airflow than high-efficiency 1-inch filters, helping to avoid "frozen coil" scenarios or high-limit trips on the furnace.
Is this compatible with 500 CFM systems?
Correct. This filter is rated for a maximum airflow capacity of 500 CFM, making it ideal for smaller branch returns or residential zones requiring 14x14 filtration.
This item is not eligible for free shipping.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
