Eaton Cutler-Hammer XTPR004BC1 Motor Protector
The Eaton Cutler-Hammer XTPR004BC1 is a robust XT Manual Motor Protector engineered for precise motor branch circuit protection in demanding industrial environments. Designed for Frame B applications, this IEC motor starter features a built-in adjustable thermal overload and high-capacity magnetic short circuit trip elements. Rated for a current range of 2.5A to 4.0A, it provides reliable Phase Loss Sensitivity and can function as a standalone manual starter or be integrated with XT series contactors for a complete motor control assembly. This unit is built to handle high interrupting capacities, ensuring the safety of downstream equipment while minimizing downtime during transient faults.
- Enhanced Protection: Class 10 adjustable bimetallic relay handles overload conditions without nuisance tripping.
- Versatile Application: Suitable for use as a Manual Motor Controller or for Group Installation protocols.
- Compact Footprint: 45mm frame width allows for high-density DIN rail mounting in control panels.
- Operator Safety: Features a lockable rotary handle and clear trip position indication for rapid diagnostics.
Common Questions
Can the XTPR004BC1 be used in field-installed control panels? Yes, it is UL listed and CSA certified for use in diverse control architectures including tap conductor protection scenarios.
Does this unit support auxiliary contact integration? Absolutely. It is compatible with side and front-mount auxiliary contacts for remote signaling and status monitoring.
Is this protector suitable for three-phase motors only? While optimized for three-phase performance and phase-failure detection, it can be utilized in single-phase applications if properly wired in series.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
Original: $151.65
-65%$151.65
$53.08Eaton Cutler-Hammer XTPR004BC1 Motor Protector
The Eaton Cutler-Hammer XTPR004BC1 is a robust XT Manual Motor Protector engineered for precise motor branch circuit protection in demanding industrial environments. Designed for Frame B applications, this IEC motor starter features a built-in adjustable thermal overload and high-capacity magnetic short circuit trip elements. Rated for a current range of 2.5A to 4.0A, it provides reliable Phase Loss Sensitivity and can function as a standalone manual starter or be integrated with XT series contactors for a complete motor control assembly. This unit is built to handle high interrupting capacities, ensuring the safety of downstream equipment while minimizing downtime during transient faults.
- Enhanced Protection: Class 10 adjustable bimetallic relay handles overload conditions without nuisance tripping.
- Versatile Application: Suitable for use as a Manual Motor Controller or for Group Installation protocols.
- Compact Footprint: 45mm frame width allows for high-density DIN rail mounting in control panels.
- Operator Safety: Features a lockable rotary handle and clear trip position indication for rapid diagnostics.
Common Questions
Can the XTPR004BC1 be used in field-installed control panels? Yes, it is UL listed and CSA certified for use in diverse control architectures including tap conductor protection scenarios.
Does this unit support auxiliary contact integration? Absolutely. It is compatible with side and front-mount auxiliary contacts for remote signaling and status monitoring.
Is this protector suitable for three-phase motors only? While optimized for three-phase performance and phase-failure detection, it can be utilized in single-phase applications if properly wired in series.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
