Eaton C320DPG11 Contactor Accessory
The Eaton C320DPG11 auxiliary contact is a critical side-mounted accessory engineered specifically for integration with 90A definite purpose (DP) contactors and Freedom Series motor starters. Designed for high-amperage motor control applications, this unit features a dual 1 N.O. and 1 N.C. contact configuration, providing reliable feedback loops and electrical interlocking for complex HVACR control circuits. Its robust construction is pilot duty rated for up to 600 VAC, ensuring stable performance in heavy-duty industrial environments where precise signaling and sequencing are required.
Installation is streamlined via the integrated pressure plate and quick connect terminals, which facilitate secure wiring for field technicians and minimize troubleshooting time. This Cutler Hammer accessory is compatible with both DP and FI series contactors, offering broad versatility for system retrofits and new builds. By utilizing a C320 Series auxiliary block, contractors can effectively monitor primary contactor states or control secondary loads without increasing the footprint of the main control panel. Each component is manufactured to meet rigorous UL and CSA standards, maintaining the integrity of the motor control center under demanding thermal and mechanical loads.
Key Benefits
- Versatile Configuration: Features both normally open and normally closed contacts (1NO-1NC) for flexible control circuit logic.
- Universal 90A Compatibility: Specifically designed to mate with Eaton 90 Amp contactors and AN16 magnetic starters.
- Simplified Wiring: Equipped with quick connect terminals and pressure plates for faster termination and reduced labor.
- Compact Side Mounting: Provides essential auxiliary feedback without increasing the depth of the contactor installation.
- Industrial Rated: Heavy duty pilot rated at 600 VAC for consistent switching performance in commercial motor control.
Common Questions
Which contactors are compatible with the C320DPG11?
This auxiliary contact is primarily designed for use with Eaton and Cutler Hammer 90A Definite Purpose contactors and FI Series motor control units. Always verify the frame size and mounting slots on your specific 90-amp model before installation.
What is the purpose of the 1 N.O. and 1 N.C. configuration?
The 1 Normally Open (N.O.) contact is typically used for status signaling or 'seal-in' circuits, while the 1 Normally Closed (N.C.) contact provides a safe electrical interlock to prevent conflicting operations, such as simultaneous forward and reverse engagement.
Can this be mounted on either side of the contactor?
Yes, the side mount design allows for flexible positioning depending on your enclosure’s internal space and wiring layout, provided the contactor frame supports side-click accessories.
