Eaton Cutler-Hammer A200MACAC Starter
The Eaton Cutler-Hammer A200MACAC is a heavy-duty NEMA Size 00 non-reversing starter engineered for reliable motor control in demanding industrial and HVACR environments. This 3-pole across-the-line starter features a 110/120V 50/60Hz AC coil and is rated for 9 Amps, making it a standard choice for single-phase or three-phase applications. Designed with an open-type enclosure, it integrates seamlessly into control panels. The unit includes an ambient compensated bimetallic manual reset thermal overload relay, providing critical protection against motor burnouts caused by sustained overcurrent conditions. Note that Type B or FH heaters are required and must be sized to the motor nameplate FLA. The A200 series is valued by technicians for its vertical design configuration and straight-through wiring, which simplifies magnetic motor starter installation and maintenance in tight footprints. Its robust contact assembly ensures a high mechanical life cycle for high-frequency switching operations.
Key Benefits for Technicians- Versatile Voltage Support: The 110/120V AC control coil is compatible with most standard industrial control circuits.
- Enhanced Thermal Protection: Features an ambient compensated overload relay to prevent nuisance tripping in varying mechanical room temperatures.
- Field-Proven Reliability: The Eaton A200 series utilizes silver-cadmium oxide contacts for superior conductivity and resistance to welding.
- Compact NEMA Size 00: Provides a rugged, NEMA rated industrial starter solution for smaller horsepower applications without consuming excessive panel space.
What heaters should be used with the A200MACAC?
This starter requires Eaton Type B thermal overload heaters or FH series heaters, which must be selected based on the specific Full Load Amps (FLA) of your motor.
Can this starter be used for single-phase motors?
Yes, the A200MACAC is rated for both single and three-phase motor loads, provided the wiring follows the manufacturer’s schematic for power phase-through.
Is the overload relay automatic or manual reset?
This specific model features a manual reset thermal overload, ensuring a technician must inspect the fault condition before restarting the equipment.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
