Eaton Cutler-Hammer 10250T2 Contact Block
The Eaton Cutler-Hammer 10250T2 Contact Block is a rugged, 30.5 mm industrial component engineered for high-reliability switching in heavy-duty environments. This standard 2NO contact block features a stackable mounting design, allowing technicians to configure up to six blocks per operator for complex 12-circuit control schemes. Built with silver contacts equipped with proprietary "reliability nibs," the 10250T2 is designed to bite through surface oxidation and fine dust, ensuring consistent electrical continuity even in low-energy dry circuits. The pressure plate terminals accommodate secure wiring for 10 A at 600 VAC and 5 A at 250 VDC, making it a versatile choice for motor control centers and industrial panels. Its thermoplastic housing is 30.5mm NEMA rated for 3, 3R, 4, 4X, 12, and 13 protection, providing superior resistance to moisture and industrial contaminants. This heavy-duty contact block is fully compatible with the 10250T series of pushbuttons and selector switches.
Key Benefits for Technicians- Enhanced Reliability: Silver-plated contacts with reliability nibs prevent performance degradation from oxidation and fine particulates.
- High-Density Control: The stackable design supports multiple circuit layers, maximizing functional density in 30.5mm control stations.
- Standardized Compatibility: Direct fit for all 10250T series operators, ensuring seamless replacement in existing industrial control panels.
- Durable Construction: Rated for NEMA 4X and 13 environments, suitable for washdown areas and oil-tight applications.
Is the 10250T2 compatible with E34 series operators?
Yes, the 10250T2 fits both the 10250T heavy-duty zinc die-cast line and the E34 corrosion-resistant line of 30.5 mm pilot devices.
What wire size is recommended for the pressure terminals?
These blocks typically accept 18 AWG to 14 AWG solid or stranded wire, ensuring a vibration-resistant connection under the pressure plate.
Can these blocks be used for logic-level switching?
While silver contacts are standard, the reliability nibs allow the 10250T2 to perform effectively in most logic-level applications without requiring specialized gold-plated blocks.
