Dwyer Instruments PG-7000-153-P1 Pressure Switch

The Dwyer Instruments PG-7000-153-P1 is a gas pressure switch designed for accurate monitoring and control of low-pressure air and gas systems. This differential pressure switch operates within a 1 to 30 inch water column range, making it suitable for HVAC applications involving airflow proving, filter monitoring, and burner system safety. Equipped with an SPDT snap switch, it provides reliable and fast contact response for consistent system control.

This HVAC pressure switch features a 4" W.C. deadband to prevent short cycling and maintain stable operation under fluctuating pressure conditions. The vertical mounting configuration ensures proper diaphragm response and accurate switching performance. Contractors commonly use this Dwyer pressure switch in duct systems, combustion air proving, and ventilation monitoring where dependable pressure sensing is critical for safe equipment operation.

Key Benefits:

• Pressure range: 1 to 30 inches water column
• SPDT snap switch for reliable contact switching
• 4" W.C. deadband for stable system control
• Vertical mounting for accurate pressure response
• Suitable for gas, air, and HVAC airflow applications

Common Questions:

• What is this switch used for?
  It is used for airflow proving, filter monitoring, and gas pressure control in HVAC systems.
• What does SPDT mean?
  Single Pole Double Throw, allowing switching between two circuits.
• Why is deadband important?
  It prevents rapid cycling by maintaining a set pressure differential before switching.

Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
