Dwyer Instruments 605-3 Transmitter
The Dwyer Instruments 605-3 is a dual-function Magnehelic differential pressure indicating transmitter designed for precise HVACR system monitoring. This unit combines the industry-standard mechanical Magnehelic gauge design with advanced Series 600 pressure transmitter technology, allowing for simultaneous local visual inspection and remote electronic control. Rated for a range of 0 to 3.0" w.c., it serves as a critical component in building automation for filter monitoring, clean room pressure maintenance, and duct static pressure control. By utilizing a 2-wire 4-20 mA output signal, it integrates seamlessly into existing control loops powered by 10-35 VDC. The 605-3 features a broad 4-inch dial for clear visibility during routine maintenance and troubleshooting. Engineered for air and non-combustible gases, this differential pressure transmitter ensures high-tier 0.5% electrical accuracy and 2% mechanical accuracy, housed in a rugged casing with 1/8" female NPT process connections for reliable field installation.
- Dual-Function Monitoring: Provides immediate local dial readings while transmitting a 4-20 mA signal to your BMS or controller.
- High-Precision Sensing: Delivers ±0.5% electrical accuracy for critical automated processes and ±2% mechanical accuracy for on-site verification.
- Versatile Compatibility: Operates on a standard 10-35 VDC power supply, making it compatible with most industrial 2-wire control loops.
- Robust Construction: Features a durable housing designed to withstand the rigors of mechanical rooms and industrial environments.
- Rapid Response: Utilizes a diaphragm-operated design that provides near-instantaneous response to pressure fluctuations without signaling delays.
Common Questions
What is the maximum pressure limit for the 605-3?
This model is rated for a maximum pressure of 2 psi (13.79 kPa). Exceeding this limit can damage the internal diaphragm and affect calibration.
Can the 605-3 be mounted in any orientation?
For maximum accuracy and to maintain the specified calibration, the transmitter should be mounted with the diaphragm in a vertical position. Mounting in other orientations may result in a zero-shift that requires manual adjustment.
What type of media is compatible with this transmitter?
The 605-3 is designed for use with air and compatible, non-combustible, non-corrosive gases. It is not intended for use with liquids or reactive chemical vapors.
This item is not eligible for free shipping.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
