Century Motors ORM1008 Motor
The Century Motors ORM1008 is a high-performance 1/8 HP condenser fan motor designed for heavy-duty HVAC service applications. Operating at 825 RPM on a single-speed 208-230V circuit, this totally enclosed air over (TEAO) motor draws only 0.7 amps, maintaining thermal efficiency in high-heat environments. It features a standard 5.6-inch diameter (48-frame) and a 1/2" x 4 13/16" shaft, making it a drop-in HVAC replacement motor for the Century 80825 and numerous OEM residential condensing units. The reversible rotation capability allows technicians to configure the motor for either clockwise or counter-clockwise operation via simple lead reversal. Equipped with Class B insulation and reinforced ball bearings, it is engineered for vertical shaft-up or shaft-down installations. This permanent split capacitor (PSC) motor requires a 5 MFD/370V capacitor (sold separately) to ensure proper starting torque and long-term HVAC system performance.
- Universal Application: Features reversible rotation and a standard 48-frame body for broad compatibility with top-tier condenser brands.
- Efficient Thermal Management: The TEAO design utilizes the system's airflow to prevent windings from overheating during continuous duty cycles.
- Precision Shaft Dimensions: The 1/2-inch diameter shaft with a 4.8-inch length ensures secure fan blade seating and minimizes vibration.
- Low Current Draw: Optimized at 0.7 amps to reduce operational costs and prevent nuisance tripping in aging electrical systems.
Common Questions
What capacitor does the ORM1008 require?
This motor requires a 5 MFD 370-volt run capacitor to operate at the specified 825 RPM and 0.7 amp rating.
Is this a direct replacement for the Century 80825?
Yes, the ORM1008 is the designated replacement for the 80825, sharing the same footprint, electrical specs, and shaft diameter.
Can this motor be mounted in any orientation?
This 48-frame motor is designed for all-angle mounting, including shaft-up, shaft-down, or horizontal configurations commonly found in condensing units.
This item is not eligible for free shipping.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
