Wayne 13122 Control
The Wayne 13122 Control is a heavy-duty oil primary control engineered for industrial burner systems requiring precise timing and high-voltage reliability. Operating at 230V / 60Hz, this Honeywell R8184G-1310 cross-reference unit manages the ignition and motor cycles with a fixed 240/45sec control interval. Designed for Wayne Combustion MSR and industrial series burners, it ensures optimal combustion by providing a 45-second safety timing window. This robust oil burner primary control is built to withstand the rigorous demands of mechanical rooms, focusing on reducing emissions through stable terminal output to the ignition transformer and burner motor.
Key Benefits for Technicians:
- Precise 240/45Sec timing optimizes fuel delivery and minimizes soot accumulation.
- Direct compatibility with Honeywell R8184G1310 ensures a seamless retrofit for 230V systems.
- Heavy-duty construction provides stable performance in high-temperature industrial environments.
- Integrated safety lockout prevents the burner from recycling during flame failure or restricted air flow.
- Standard terminal layout allows for straightforward wiring of the CAD cell and limit strings.
Common Questions:
How do I troubleshoot a lockout on this control?
First, verify 230V power at the input. If the burner starts but trips the 45-second safety, inspect the CAD cell resistance; it must be below 1600 ohms during the run cycle to maintain flame proofing.
Is this unit compatible with 120V burners?
No, the 13122 is specifically rated for 230V applications. Using this on a 120V circuit will cause the components to fail or not energize the ignition sequence.
What does the 240/45 timing signify?
The 240 refers to the total duty cycle parameters, while the 45 represents the 45-second safety timing, which is the window the control allows for flame establishment before locking out.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
Wayne 13122 Control
The Wayne 13122 Control is a heavy-duty oil primary control engineered for industrial burner systems requiring precise timing and high-voltage reliability. Operating at 230V / 60Hz, this Honeywell R8184G-1310 cross-reference unit manages the ignition and motor cycles with a fixed 240/45sec control interval. Designed for Wayne Combustion MSR and industrial series burners, it ensures optimal combustion by providing a 45-second safety timing window. This robust oil burner primary control is built to withstand the rigorous demands of mechanical rooms, focusing on reducing emissions through stable terminal output to the ignition transformer and burner motor.
Key Benefits for Technicians:
- Precise 240/45Sec timing optimizes fuel delivery and minimizes soot accumulation.
- Direct compatibility with Honeywell R8184G1310 ensures a seamless retrofit for 230V systems.
- Heavy-duty construction provides stable performance in high-temperature industrial environments.
- Integrated safety lockout prevents the burner from recycling during flame failure or restricted air flow.
- Standard terminal layout allows for straightforward wiring of the CAD cell and limit strings.
Common Questions:
How do I troubleshoot a lockout on this control?
First, verify 230V power at the input. If the burner starts but trips the 45-second safety, inspect the CAD cell resistance; it must be below 1600 ohms during the run cycle to maintain flame proofing.
Is this unit compatible with 120V burners?
No, the 13122 is specifically rated for 230V applications. Using this on a 120V circuit will cause the components to fail or not energize the ignition sequence.
What does the 240/45 timing signify?
The 240 refers to the total duty cycle parameters, while the 45 represents the 45-second safety timing, which is the window the control allows for flame establishment before locking out.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
