Wayne 13077 Control
The Wayne 13077 Control is a heavy-duty 120V ignition control designed specifically for demand-heavy oil burner applications. Engineered with a 15-second safety timing (lockout), this primary control serves as the central logic unit for the burner, monitoring flame safety and sequence of operation. It is frequently utilized in Wayne oil burners and commercial heating systems where a R8184G1294 primary control equivalent is required. As a veteran-grade oil burner primary control, the 13077 manages the cad cell circuit to ensure consistent ignition and prevents hazardous oil accumulation in the combustion chamber. The design prioritizes combustion efficiency by synchronizing the blower motor, ignitor, and fuel pump cycles with high precision. For contractors replacing legacy controls, the 13077 provides a reliable, direct-fit solution that stabilizes flame sensing and improves overall HVAC system diagnostics during routine maintenance or emergency service calls.
Key Benefits for Technicians:
- Precise 15-Second Lockout: Provides critical flame safety by shutting down the system quickly if ignition is not established, preventing fuel saturation.
- Universal 120V Compatibility: Designed for seamless integration with standard oil burner electrical systems and is a verified equivalent for the Wayne Combustion 13077.
- Robust Solid-State Engineering: Built to withstand the high-temperature environments of commercial mechanical rooms while maintaining accurate timing cycle intervals.
- Simplified Wiring: Features standard terminal markings that expedite furnace repair and minimize downtime during control board swaps.
Common Questions:
Can the Wayne 13077 replace an R8184G style control?
Yes, the 13077 is functionally compatible with many primary controls featuring a 15-second safety timing and 120V input. Always verify the cad cell resistance and specific burner application before installation.
What does it mean if the control locks out in 15 seconds?
This indicates the oil primary control did not sense a flame via the cad cell within the safety interval. This is a safety feature to prevent the burner from dumping unburned fuel into the heat exchanger.
Is this control suitable for residential oil burners?
The 13077 is widely used in both residential heating and light commercial Wayne burners. Ensure your specific unit is rated for 120V operation and matches the 15-second lockout requirement.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
