Watts F602-036A Filter
The Watts F602-036A air filter is a high-performance 3/8 NPT compressed air filter engineered for heavy-duty pneumatic systems requiring superior moisture and particulate removal. Designed with a robust zinc die-cast body and a 4.4-ounce polycarbonate bowl, this unit features a specialized internal deflector plate that creates a swirling centrifugal airflow. This design ensures maximum separation of liquid water and contaminants before they reach the 40 micron polypropylene filter element, protecting downstream valves and cylinders from premature wear. With a high flow capacity of 80 SCFM at 150 PSIG and a low pressure drop, the F602-036A maintains system efficiency across variable loads. This model comes standard with an automatic float drain, making it an ideal "install and forget" solution for contractors working in tight mechanical spaces where manual draining is impractical.
Key Benefits- Efficient Water Separation: The internal deflector plate optimizes centrifugal force to strip bulk liquids from the airstream effectively.
- High Flow Performance: Rated for 80 SCFM, ensuring minimal restriction in standard 3/8-inch pneumatic piping runs.
- Automated Maintenance: Features an integrated internal automatic float drain that discharges collected condensate without operator intervention.
- Durable Construction: The zinc housing and polypropylene element provide excellent chemical resistance and structural integrity in industrial environments.
- Optimized Filtration: The 40 micron rating balances high airflow with effective contaminant capture to prevent pneumatic component fouling.
- What is the maximum operating pressure? This unit is rated for a maximum inlet pressure of 150 PSIG.
- Can this filter be used with synthetic oils? Caution is advised as polycarbonate bowls can be degraded by certain synthetic compressor oils and chemicals; for those applications, a metal bowl version is recommended.
- Is the filter element replaceable? Yes, the 40 micron element can be swapped out during routine maintenance to maintain peak flow characteristics.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
Original: $401.20
-65%$401.20
$140.42Watts F602-036A Filter
The Watts F602-036A air filter is a high-performance 3/8 NPT compressed air filter engineered for heavy-duty pneumatic systems requiring superior moisture and particulate removal. Designed with a robust zinc die-cast body and a 4.4-ounce polycarbonate bowl, this unit features a specialized internal deflector plate that creates a swirling centrifugal airflow. This design ensures maximum separation of liquid water and contaminants before they reach the 40 micron polypropylene filter element, protecting downstream valves and cylinders from premature wear. With a high flow capacity of 80 SCFM at 150 PSIG and a low pressure drop, the F602-036A maintains system efficiency across variable loads. This model comes standard with an automatic float drain, making it an ideal "install and forget" solution for contractors working in tight mechanical spaces where manual draining is impractical.
Key Benefits- Efficient Water Separation: The internal deflector plate optimizes centrifugal force to strip bulk liquids from the airstream effectively.
- High Flow Performance: Rated for 80 SCFM, ensuring minimal restriction in standard 3/8-inch pneumatic piping runs.
- Automated Maintenance: Features an integrated internal automatic float drain that discharges collected condensate without operator intervention.
- Durable Construction: The zinc housing and polypropylene element provide excellent chemical resistance and structural integrity in industrial environments.
- Optimized Filtration: The 40 micron rating balances high airflow with effective contaminant capture to prevent pneumatic component fouling.
- What is the maximum operating pressure? This unit is rated for a maximum inlet pressure of 150 PSIG.
- Can this filter be used with synthetic oils? Caution is advised as polycarbonate bowls can be degraded by certain synthetic compressor oils and chemicals; for those applications, a metal bowl version is recommended.
- Is the filter element replaceable? Yes, the 40 micron element can be swapped out during routine maintenance to maintain peak flow characteristics.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
