Trane BRD1335 Board
For field techs and contractors maintaining Trane equipment, the Trane BRD1335 24V Main Connection Board is the standard OEM replacement for managing signal flow between the thermostat, compressor, and blower motor. This HVAC control board acts as the master communication bridge, ensuring precise 24VAC control across the entire circuit. If you are troubleshooting a unit where the components aren't communicating or the 24V signal is lost at the distribution point, swapping in a genuine Trane BRD1335 restores factory-spec reliability immediately.
The BRD1335 Trane board is engineered for high-use environments and rated for 50/60Hz operations. It features a rugged, integrated 24V board with mounting bracket, designed specifically for rapid installation inside air handlers or furnaces. By using a real Trane OEM part, you avoid the pinout discrepancies and voltage drops common with generic alternatives, maintaining the integrity of the system's electrical logic and safeguarding sensitive downstream components.
Key Benefits for HVAC Professionals:
- OEM Compatibility: Specifically designed to match original factory specifications for Trane and American Standard systems, ensuring a direct fit without modifications.
- Enhanced Signal Reliability: Stabilizes the communication bridge between the thermostat and major mechanical components for consistent temperature control.
- Integrated Mounting Solution: Ships with a pre-installed bracket to reduce bench time and secure the board against cabinet vibration.
- Industrial Build Quality: Constructed with high-grade traces and connectors to withstand the thermal stress of furnace and AHU environments.
Common Questions:
Is the BRD1335 compatible with 50Hz and 60Hz systems?
Yes, this main connection board is rated for both 50Hz and 60Hz 24VAC control circuits, making it suitable for a wide range of residential and light commercial equipment.
Can this board replace non-bracketed Trane connection boards?
The BRD1335 includes an integrated mounting bracket. If you are replacing an older revision, such as the BRD01335, this OEM version provides the necessary hardware for a secure update.
What components does this board interface with?
It serves as the central junction for 24V wiring, routing signals from the thermostat to the compressor contactor, blower relay, and auxiliary safety switches.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
Original: $487.29
-65%$487.29
$170.55Trane BRD1335 Board
