Sporlan 903532P Valve
The Sporlan 903532P is a high-performance ADRPE-3 discharge bypass valve designed to provide precise hot gas bypass control for commercial HVAC and refrigeration systems. This externally equalized, pilot-operated valve features a 0/80# pressure adjustment range, allowing technicians to maintain constant evaporator pressures during periods of low load. The 5/8" ODF solder connections facilitate seamless integration into standard refrigerant piping configurations. By diverting discharge gas to the low side, the ADRPE-3 prevents compressor short-cycling and evaporator icing, ensuring superior humidity control and oil return. Engineered for durability, this valve is compatible with modern refrigerants and is essential for maintaining load balance in variable capacity systems. Contractors rely on the Sporlan ADRPE series for its consistent modulation and field-adjustable sensitivity, making it a critical component for optimizing system longevity and reducing operational wear on the compressor.
Key Technical Benefits- Constant Evaporator Pressure: Maintains precise suction pressure to prevent coil freeze-ups during low-load conditions.
- Field-Adjustable Range: The 0 to 80 psi adjustment allows for specific tuning based on system design and refrigerant type.
- Pilot-Operated Design: Offers superior sensitivity and modulation compared to direct-acting valves for larger capacity requirements.
- Reduced Compressor Stress: Minimizes cycling frequency, protecting the motor and ensuring consistent oil migration.
- 5/8" ODF Connections: Standard copper-to-copper sweat connections for a leak-free, professional installation.
What is the primary function of the Sporlan ADRPE-3?
This valve acts as a modulating discharge bypass valve, diverting hot gas to the evaporator or suction line to compensate for a decrease in system load, thereby stabilizing suction pressure.
Can the pressure setting be adjusted in the field?
Yes, the 0/80# range is fully adjustable, allowing technicians to calibrate the bypass start point to match the specific requirements of the refrigeration circuit.
Is external equalization required for this model?
The ADRPE-3 is an externally equalized valve, which is necessary for accurate sensing of the evaporator pressure downstream of the distributor, ensuring the valve responds correctly to load changes.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
