Sporlan 761805 Drier
When you're dealing with today's high-performance heat pump systems, the Sporlan 761805 Drier, also known as the HPC-103-S, is a critical component for ensuring long-term system reliability. This bi-flow filter drier is specifically designed for liquid line applications in reversible cycles, featuring internal check valves that direct refrigerant through the desiccant core regardless of the flow direction. With its 3/8" ODF solid copper solder connections, it integrates seamlessly into residential and commercial HVACR systems up to 5 tons. The unit utilizes a 10-cubic-inch molded porous core, engineered for maximum moisture and acid removal while maintaining a low pressure drop. Its heavy-duty construction is UL listed for a 650 psig rated pressure, making it fully compatible with R-410A, HFC, HCFC, and HFO refrigerants. By capturing solid debris and neutralizing contaminants, the Sporlan HPC-103-S protects sensitive upstream components like thermostatic expansion valves and compressors from premature failure.
Key Benefits:- Optimized Contaminant Control: The high-performance desiccant package provides superior acid and water capacity to prevent system corrosion and oil breakdown.
- Reversible Flow Efficiency: Stainless steel check valves ensure that solid debris stays trapped within the core, even when the heat pump reverses cycle.
- Broad Refrigerant Compatibility: Suitable for use with modern refrigerants including R-410A, R-22, and R-407C, as well as sub-critical CO2 applications.
- Durable Shell Design: Features an epoxy powder-coated finish for exceptional corrosion resistance in harsh outdoor environments.
- Precise Filtration: The porous molded core effectively captures solid particles to prevent blockages in the refrigeration circuit.
- Can I use this drier on a standard air conditioning unit that isn't a heat pump? While designed for bi-flow heat pump applications, it functions effectively as a standard liquid line drier, though a dedicated uni-directional Catch-All may be more cost-effective for cooling-only systems.
- Is the HPC-103-S compatible with POE oil? Yes, the desiccant blend remains highly effective for systems using Polyolester (POE) lubricants typical of HFC/HFO installations.
- Does this drier require a specific mounting orientation? For optimal performance, it is best practice to install the drier in a vertical position with flow directed downward, though it is rated for horizontal installation if necessary.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
