Sporlan 502058 Valve
The Sporlan 502058, also identified as the Model EBVP-1070, is a high-performance bi-directional refrigeration ball valve engineered for critical liquid, suction, and discharge line applications. This 7/8" ODF ball valve features a full-port design to minimize pressure drop and maximize flow capacity across the system. Constructed with a forged brass body and extended copper ends, it allows for streamlined brazing without disassembly, maintaining seal integrity. The integrated access port facilitates convenient pressure monitoring and charging, while the secondary seal cap ensures a leak-tight configuration. Designed specifically for high-pressure refrigerants, including R-410A and R-134a, this valve provides a 700 psi maximum rated pressure (MRP). The internal PTFE seats and Gylon stem seals provide superior chemical resistance and thermal stability, making this a reliable component for commercial refrigeration and HVAC service contractors requiring precise refrigerant flow control.
Key Benefits for Technicians- Full port construction eliminates restrictive flow paths to maintain system efficiency and lower compression ratios.
- Hermetic stem design utilizes a dual-seal approach to prevent refrigerant loss in high-vibration environments.
- Internal rupture-proof stem enhances safety by preventing stem blowout under extreme pressure spikes.
- Bi-directional flow capability allows for versatile installation in heat pump reverse cycles or complex piping layouts.
- Integrated Schrader access port simplifies diagnostics and evacuation procedures without additional line taps.
What is the maximum working pressure for the EBVP-1070?
This valve is rated for a Maximum Rated Pressure (MRP) of 700 psig, making it suitable for modern high-pressure refrigerant applications.
Does this valve require disassembly before brazing?
No, the extended copper fittings are designed to dissipate heat, allowing for installation without dismantling the internal seals, provided standard heat-sinking practices are followed.
Can this ball valve be mounted in any orientation?
Yes, the Sporlan EBVP series is designed for universal mounting, though it is professional practice to ensure the access port remains accessible for future service.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
Original: $103.29
-65%$103.29
$36.15Sporlan 502058 Valve
The Sporlan 502058, also identified as the Model EBVP-1070, is a high-performance bi-directional refrigeration ball valve engineered for critical liquid, suction, and discharge line applications. This 7/8" ODF ball valve features a full-port design to minimize pressure drop and maximize flow capacity across the system. Constructed with a forged brass body and extended copper ends, it allows for streamlined brazing without disassembly, maintaining seal integrity. The integrated access port facilitates convenient pressure monitoring and charging, while the secondary seal cap ensures a leak-tight configuration. Designed specifically for high-pressure refrigerants, including R-410A and R-134a, this valve provides a 700 psi maximum rated pressure (MRP). The internal PTFE seats and Gylon stem seals provide superior chemical resistance and thermal stability, making this a reliable component for commercial refrigeration and HVAC service contractors requiring precise refrigerant flow control.
Key Benefits for Technicians- Full port construction eliminates restrictive flow paths to maintain system efficiency and lower compression ratios.
- Hermetic stem design utilizes a dual-seal approach to prevent refrigerant loss in high-vibration environments.
- Internal rupture-proof stem enhances safety by preventing stem blowout under extreme pressure spikes.
- Bi-directional flow capability allows for versatile installation in heat pump reverse cycles or complex piping layouts.
- Integrated Schrader access port simplifies diagnostics and evacuation procedures without additional line taps.
What is the maximum working pressure for the EBVP-1070?
This valve is rated for a Maximum Rated Pressure (MRP) of 700 psig, making it suitable for modern high-pressure refrigerant applications.
Does this valve require disassembly before brazing?
No, the extended copper fittings are designed to dissipate heat, allowing for installation without dismantling the internal seals, provided standard heat-sinking practices are followed.
Can this ball valve be mounted in any orientation?
Yes, the Sporlan EBVP series is designed for universal mounting, though it is professional practice to ensure the access port remains accessible for future service.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
