Sporlan 502053 Ball Valve
The Sporlan 502053, professionally designated as the EBVP-1020 ball valve, is a critical component for contractors managing high-pressure refrigerant flow control. This 1/4 inch ODF ball valve features a robust forged brass body with extended copper fittings, allowing for efficient brazing without internal component degradation. Designed with a full port architecture, it ensures minimal pressure drop across the line while maintaining a high flow coefficient (Cv of 2.1). The inclusion of a 1/4 inch SAE Schrader access port allows for immediate pressure diagnostics or charging during service. Engineered for extreme duty, this bi-directional ball valve handles a design working pressure of 700 psig and service temperatures ranging from -40°F to +325°F. The internal assembly utilizes a polished brass ball seated between dual Teflon seals, providing a bubble-tight shut-off. A stainless steel stop plate ensures a precise 90-degree turn from full open to full closed, while the internal relief port prevents pressure traps during system evacuation or isolation.
Key Benefits- Internal Relief Port: Prevents internal pressure build-up behind the ball, ensuring positive shut-off and safer system evacuation.
- Leak-Free Performance: Factory-tested welded body joint and dual PTFE seats eliminate atmospheric and across-the-seat leakage.
- Universal Compatibility: Rated for use with all major CFC, HCFC, and HFC refrigerants, including R-410A and R-404A systems.
- Installation Versatility: Bi-directional flow capability and compact footprint allow for mounting in any orientation in tight mechanical spaces.
- Service Convenience: Integrated Schrader valve facilitates rapid pressure checks without breaking the primary circuit.
Is this valve suitable for suction line applications?
Yes, the EBVP-1020 is rated for suction, discharge, and liquid line applications, provided the 1/4" ODF sizing meets your system's mass flow requirements.
Does this valve require disassembly before brazing?
No, Sporlan EBVP valves are designed for direct installation. However, technicians should wrap the valve body with a wet rag to dissipate heat and protect the dual Teflon seals during the brazing process.
Can the handle be locked in position?
The valve features a stainless steel stop plate that provides a hard stop for the 1/4 turn operation, but it does not include a managed locking mechanism for security tagging.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
