Sporlan 450274-001 Filter
The Sporlan 450274-001 Filter, specifically the LLD 052 1/4" SAE Male FILTER, is a high-performance liquid line filter drier designed for precise contaminant control in light commercial and residential HVACR applications. Engineered with a 5 cubic inch desiccant volume, this sealed model utilizes a premium 75% molecular sieve and 25% activated alumina blend to effectively capture moisture, organic acids, and solid debris. The 1/4" SAE male flare connections utilize nickel-plated fittings to ensure leak-proof stability under high-pressure conditions, supporting a maximum rated pressure of 650 PSI. This HVAC liquid line drier is universally compatible with all CFC, HCFC, and HFC refrigerants, including R-22, R-410A, and R-407C, making it an essential component for protecting the thermal expansion valve (TEV) and compressor from premature failure. The steel shell is finished with a corrosion-resistant powder coating, capable of withstanding extreme environmental exposure in refrigeration systems ranging from 1/3 to 2 tons.
Key Benefits- Optimized Contaminant Removal: The dual-desiccant core provides high water and acid capacity to stabilize refrigerant chemistry and prevent internal corrosion.
- Broad Refrigerant Compatibility: Field-ready for multiple refrigerant types like R-410A and R-134a, allowing for consolidated inventory management.
- Durable Construction: Features a heavy-gauge steel shell and nickel-plated flare fittings for a long-lasting seal in high-vibration refrigeration systems.
- Debris Filtration: Protects downstream components by trapping solid particles down to 40 microns, ensuring reliable HVAC part performance.
- Simplified Installation: Standard 1/4 inch SAE connections allow for rapid field replacement without the need for specialized brazing in sensitive areas.
Is the Sporlan LLD 052 compatible with POE oils?
Yes, the Sporlan 450274-001 is fully compatible with polyolester (POE) oils and traditional mineral oils, ensuring it won't strip additives during liquid line filtration.
What is the flow capacity of this filter drier?
For R-410A systems, it is rated for up to 1.5 tons, and for R-22 systems, it handles up to approximately 2 tons at a 1 PSI pressure drop.
Can this be used on the suction side?
No, the LLD 052 1/4" SAE Male is specifically designed as a liquid line sealed model. Suction line service requires a high-flow model designed for vapor-phase contaminants.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
Original: $22.43
-65%$22.43
$7.85Sporlan 450274-001 Filter
The Sporlan 450274-001 Filter, specifically the LLD 052 1/4" SAE Male FILTER, is a high-performance liquid line filter drier designed for precise contaminant control in light commercial and residential HVACR applications. Engineered with a 5 cubic inch desiccant volume, this sealed model utilizes a premium 75% molecular sieve and 25% activated alumina blend to effectively capture moisture, organic acids, and solid debris. The 1/4" SAE male flare connections utilize nickel-plated fittings to ensure leak-proof stability under high-pressure conditions, supporting a maximum rated pressure of 650 PSI. This HVAC liquid line drier is universally compatible with all CFC, HCFC, and HFC refrigerants, including R-22, R-410A, and R-407C, making it an essential component for protecting the thermal expansion valve (TEV) and compressor from premature failure. The steel shell is finished with a corrosion-resistant powder coating, capable of withstanding extreme environmental exposure in refrigeration systems ranging from 1/3 to 2 tons.
Key Benefits- Optimized Contaminant Removal: The dual-desiccant core provides high water and acid capacity to stabilize refrigerant chemistry and prevent internal corrosion.
- Broad Refrigerant Compatibility: Field-ready for multiple refrigerant types like R-410A and R-134a, allowing for consolidated inventory management.
- Durable Construction: Features a heavy-gauge steel shell and nickel-plated flare fittings for a long-lasting seal in high-vibration refrigeration systems.
- Debris Filtration: Protects downstream components by trapping solid particles down to 40 microns, ensuring reliable HVAC part performance.
- Simplified Installation: Standard 1/4 inch SAE connections allow for rapid field replacement without the need for specialized brazing in sensitive areas.
Is the Sporlan LLD 052 compatible with POE oils?
Yes, the Sporlan 450274-001 is fully compatible with polyolester (POE) oils and traditional mineral oils, ensuring it won't strip additives during liquid line filtration.
What is the flow capacity of this filter drier?
For R-410A systems, it is rated for up to 1.5 tons, and for R-22 systems, it handles up to approximately 2 tons at a 1 PSI pressure drop.
Can this be used on the suction side?
No, the LLD 052 1/4" SAE Male is specifically designed as a liquid line sealed model. Suction line service requires a high-flow model designed for vapor-phase contaminants.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
The Sporlan 450274-001 Filter, specifically the LLD 052 1/4" SAE Male FILTER, is a high-performance liquid line filter drier designed for precise contaminant control in light commercial and residential HVACR applications. Engineered with a 5 cubic inch desiccant volume, this sealed model utilizes a premium 75% molecular sieve and 25% activated alumina blend to effectively capture moisture, organic acids, and solid debris. The 1/4" SAE male flare connections utilize nickel-plated fittings to ensure leak-proof stability under high-pressure conditions, supporting a maximum rated pressure of 650 PSI. This HVAC liquid line drier is universally compatible with all CFC, HCFC, and HFC refrigerants, including R-22, R-410A, and R-407C, making it an essential component for protecting the thermal expansion valve (TEV) and compressor from premature failure. The steel shell is finished with a corrosion-resistant powder coating, capable of withstanding extreme environmental exposure in refrigeration systems ranging from 1/3 to 2 tons.
Key Benefits- Optimized Contaminant Removal: The dual-desiccant core provides high water and acid capacity to stabilize refrigerant chemistry and prevent internal corrosion.
- Broad Refrigerant Compatibility: Field-ready for multiple refrigerant types like R-410A and R-134a, allowing for consolidated inventory management.
- Durable Construction: Features a heavy-gauge steel shell and nickel-plated flare fittings for a long-lasting seal in high-vibration refrigeration systems.
- Debris Filtration: Protects downstream components by trapping solid particles down to 40 microns, ensuring reliable HVAC part performance.
- Simplified Installation: Standard 1/4 inch SAE connections allow for rapid field replacement without the need for specialized brazing in sensitive areas.
Is the Sporlan LLD 052 compatible with POE oils?
Yes, the Sporlan 450274-001 is fully compatible with polyolester (POE) oils and traditional mineral oils, ensuring it won't strip additives during liquid line filtration.
What is the flow capacity of this filter drier?
For R-410A systems, it is rated for up to 1.5 tons, and for R-22 systems, it handles up to approximately 2 tons at a 1 PSI pressure drop.
Can this be used on the suction side?
No, the LLD 052 1/4" SAE Male is specifically designed as a liquid line sealed model. Suction line service requires a high-flow model designed for vapor-phase contaminants.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
