Sporlan 450095-001 Filter Core
As a technician, you know that compressor burnout and wax buildup are the primary killers of low-temperature systems. The Sporlan 450095-001 PCK-48HH is a 48 cubic inch replaceable filter drier core engineered specifically for these high-stakes clean-up scenarios. Utilizing a specialized activated charcoal blend, this core excels at removing wax, resins, and lubricant breakdown materials that standard desiccants miss. Whether you are dealing with a hermetic motor burnout or a system exposed to the atmosphere, the PCK-48HH provides high-capacity acid and moisture removal along both liquid and suction line applications. Its porous molded design ensures low pressure drop across the 48 cu. in. volume, maintaining optimal mass flow while capturing solids and sludge that could otherwise clog expansion valves or damage new compressors. This high-performance desiccant package is a critical component for any contractor performing refrigerant reclaim or recovery deep-cleans.
Key Benefits for HVACR Professionals- Charcoal-Activated Filtration: Formulated to pull wax and scorched oil out of solution in low-temp systems before they reach the metering device.
- Burnout Recovery: Integrated high-performance desiccants manage acid and moisture levels after catastrophic motor failure.
- Universal Shell Compatibility: Designed to fit Sporlan C-480 through C-19200 series shells and RSF suction filter shells.
- High Solids Capacity: The porous molded structure traps sludge and metallic debris without significantly sacrificing system pressure.
- Broad Refrigerant Range: Compatible with most modern CFC, HCFC, and HFC refrigerants and their associated lubricants.
When should I choose the HH charcoal core over a standard RC-4864?
Use the PCK-48HH when you suspect wax buildup in low-temperature refrigeration or when cleaning up after a compressor burnout. The activated charcoal is specifically included to remove organic contaminants like varnish and resins that standard cores cannot trap.
Can this be used in the suction line for permanent filtration?
While it can be used in suction lines for clean-up, it is typically recommended as a temporary measure during system remediation. For permanent suction line filtration with the lowest possible pressure drop, you may transition to a pleated element once the system is verified clean.
How does this core handle POE oil systems?
The PCK-48HH is highly effective in systems using POE or mineral oils, particularly when those oils have begun to break down into acids and sludge due to high heat or moisture ingress.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
