Siemens Industrial Controls 3TX7114-5LC13 Relay
The Siemens 3TX7114-5LC13 is a robust DPDT plug-in output relay designed for reliable switching in industrial control circuits and HVACR automation. Engineered for high-density mounting, this 10 Amp power relay features a 120V AC coil and is optimized for use with 3TX71 series sockets. The integrated LED status indicator provides immediate visual confirmation of coil energization, streamlining troubleshooting in complex control panels. This interposing relay utilizes silver-nickel contacts to ensure long-term electrical conductivity and resistance to contact welding under inductive loads.
When selecting a Siemens Sirius 3TX71 relay for motor control or solenoid sequencing, performance stability is critical. This unit facilitates secondary circuit isolation, protecting sensitive PLC outputs from high-current field devices. The compact DIN rail mount relay design allows for efficient space management within NEMA enclosures, making it a standard choice for 120VAC control relay replacements in existing infrastructure.
Technical Application Benefits
- DPDT Contact Configuration: Supports simultaneous switching of two independent circuits, ideal for interlocking applications.
- Integrated LED Diagnostic: Reduces downtime by allowing technicians to verify voltage presence at the coil without a multimeter.
- High Contact Rating: Rated for 10A at 250V AC, capable of handling pilot duty and small motor loads.
- Compact Footprint: Designed for high-density 8-pin plug-in configurations to maximize enclosure efficiency.
Common Technical Questions
What is the primary application for the Siemens 3TX7114-5LC13?
This relay is primarily used as an interposing or output relay to bridge the gap between low-power control signals and high-power operational components like heaters or contactors.
Can I use this relay for DC switching?
While optimized for 120V AC coil applications, the contacts can handle DC loads; however, de-rating is necessary based on the specific DC voltage and inductive properties of the load.
Is the LED indicator replaceable?
The LED is integrated into the relay housing and is not a separate serviceable part. If the LED fails but the contacts operate, the unit is still functional, though visual diagnostics will be lost.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
