Siemens Industrial Controls 3TX7110-5BC03C Relay
The Siemens Industrial Controls 3TX7110-5BC03C Relay is a heavy-duty 24VDC 15Amp SPDT Relay designed for critical switching applications in industrial automation and HVACR control circuits. This plug-in relay features a basic 5-pin square base configuration, engineered for high-cycle reliability with a contact rating capable of handling up to 20A at 120/240VAC. Built for the rigors of field service, the unit utilizes a SIRIUS power relay architecture to ensure stable performance under varied thermal conditions, ranging from -40 to 55 degrees Celsius. The compact Siemens 3TX71 series design facilitates easy integration into existing control panels when paired with the 3TX7144-4E7 socket. By consolidating multi-voltage switching capabilities into a single-pole, double-throw (SPDT) form factor, this relay optimizes footprint while maintaining the electrical endurance needed for inductive motor loads and resistive heating elements. For contractors maintaining legacy or modern industrial systems, this component provides the exact electrical specifications required for industrial control relay replacement, ensuring minimal downtime and precise operation in demanding environments.
Key Benefits- High Current Capacity: Rated for 15A continuous duty and up to 20A at 240VAC, making it suitable for motor starters and industrial lighting.
- Universal Compatibility: Standard 5-pin square base ensures a direct fit with the 3TX7144-4E7 plug-in socket for fast field installation.
- Rugged Environmental Spec: Operates efficiently in extreme temperatures, essential for unconditioned mechanical rooms and industrial cabinets.
- Reliable DC Coil: The 24VDC coil is optimized for low power consumption (0.7W) while providing crisp, repeatable contact engagement.
- What socket does the 3TX7110-5BC03C require? This relay is designed for use with the Siemens 3TX7144-4E7 square base socket.
- Can this relay replace a higher-amperage unit? It is rated for 15A/20A applications; always verify that the load of your specific HVACR equipment does not exceed these values.
- Is this suitable for AC control voltage? No, this specific model features a 24VDC coil. For AC applications, verify the coil voltage prefix on your existing relay.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
Original: $12.98
-65%$12.98
$4.54Siemens Industrial Controls 3TX7110-5BC03C Relay
