Siemens Building Technology 7MF15654BG005EA1 Sensor
The Siemens SITRANS P200 7MF15654BG005EA1 is a high-performance gauge pressure transmitter designed for precision monitoring in demanding HVACR and industrial hydraulic systems. This liquid pressure sensor features a robust piezo-resistive measuring system with a ceramic diaphragm, ensuring high accuracy (typically 0.25% of full scale) and resistance to mechanical aging or creepage. Built with a sturdy stainless steel housing, the unit is engineered to handle both aggressive and non-aggressive media, including liquids, gases, and vapors. The 4-20mA output signal provides a linear representation of the 0 to 100 PSIG range, suitable for integration with standard PLC and DDC building automation controllers via a secure terminal block connection. Its fully encapsulated electronics offer superior protection against ambient humidity and temperature fluctuations, providing stable measurements in environments ranging from -13 to 185 degrees Fahrenheit. This sensor is an ideal solution for contractors requiring a reliable process connection for static and dynamic pressure monitoring without the need for a local display.
Key Benefits- Exceptional Durability: The stainless steel enclosure and ceramic sensing element provide long-term stability and protection against corrosive media.
- Technical Precision: Maintains a 0.25% typical accuracy rating, ensuring reliable data for critical system adjustments and HVAC pressure monitoring.
- Versatile Media Compatibility: Suitable for measuring the pressure of liquids, gases, and steam, making it a "go-to" part for varied mechanical room applications.
- Compact Integration: The space-saving design and standard 1/4 inch MNPT process connection allow for easy installation in tight manifold configurations.
- Thermal Stability: Temperature-compensated measuring cell prevents drift, maintaining signal integrity across a wide operating temperature range.
What is the maximum overload pressure for this sensor?
The 7MF1565-4BG00-5EA1 typically supports an overload pressure of up to 200 psi for this specific 100 psi range, though always verify your specific system peak pressures before installation.
Can this transmitter be used with steam?
Yes, it is rated for vapor; however, for steam applications, a syphon loop (pigtail) should be used to protect the ceramic measuring cell from direct high-temperature steam contact.
Does this unit require a separate power supply?
The 4-20mA output is a standard two-wire configuration, typically powered by a 7 to 33 V DC supply from the controller or an external source.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
