Siemens Building Technology 599-02071 Valve
The Siemens Building Technology 599-02071 is a commercial-grade 1-inch 3-way mixing globe valve from the Powermite 599 MT Series. Engineered for precision hydronic control, this 10 Cv valve body features a durable forged brass body with brass trim, maintaining high performance in demanding terminal unit applications. Designed with an ANSI Class 250 rating, it supports water and glycol solutions (up to 50%) within a temperature range of 35°F to 250°F. The NPT female-to-female connections allow for seamless integration into existing pipework, while the linear flow characteristic ensures stable modulation. A direct-coupled universal bonnet facilitates rapid installation, requiring no specialized tools for mounting compatible MT series electronic or pneumatic actuators. This HVAC zone valve is a standard for contractors seeking reliable mixing performance and ANSI Leakage Class IV efficiency in chiller or boiler loops.
Key Benefits- High-Durability Construction: The forged brass body and brass trim provide corrosion resistance and long-term reliability in closed-loop systems.
- Universal Compatibility: Specifically designed to interface with Siemens MT Series actuators using a 7/32-inch (5.5 mm) stroke and 67 lbf (300 N) of force.
- Efficient Mixing Performance: The 3-way mixing valve configuration naturally handles varying flow demands with a 10 Cv flow coefficient.
- Tool-Free Mounting: Features a direct-coupled bonnet design, significantly reducing labor time during field installation or actuator replacement.
- Technical Precision: Rated for ANSI Class 250 pressure environments and Class IV leakage standards, ensuring minimal energy loss.
Can the 599-02071 be used for steam applications?
This specific model features brass trim and is primarily rated for water and glycol. For steam service up to 15 psi, a stainless steel trim variant is generally required.
Which actuators are compatible with this valve body?
The 599-02071 is designed for use with Siemens Powermite MT Series actuators, including the SFA, SFP, SSA, and SSP series electronic actuators, as well as compatible pneumatic options.
Is this a mixing or diverting valve?
This is a 3-way mixing valve, meaning it is designed with two inlets and one common outlet to blend hot and cold water streams.
This item is not eligible for free shipping.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
