Siemens Building Technology 599-01138 Valve
The Siemens Building Technology 599-01138 is a high-performance 3-way mixing valve designed for precise flow control in demanding hydronic systems. This Powermite 599 MZ Series valve body features a 3/4 inch NPT connection and a 6.3 Cv rating, making it an ideal choice for regulating hot or chilled water and water-glycol solutions up to 50% concentration. Built with a rugged forged brass body and brass trim, this globe-style valve is engineered for longevity and performance in terminal units like fan coils, induction units, and small reheat coils.
For contractors in the field, the 599-01138 offers ease of installation with its direct-coupled universal bonnet, allowing for seamless integration with Siemens SSB actuators. The valve operates with a linear flow characteristic and is rated for ANSI Class 250 pressure requirements, providing a reliable close-off even in high-pressure environments. With a temperature range of 35°F to 250°F, this 3-port threaded valve ensures consistent modulating control and meets ANSI Leakage Class IV standards, minimizing energy loss and system bypass when closed.
Key Benefits
- Optimized Mixing Performance: Specifically engineered for 3-way mixing applications to maintain precise discharge temperatures in HVAC circuits.
- Durable Construction: The forged brass body and stainless steel stem resist corrosion and wear in treated water systems.
- High Compatibility: Designed to work natively with Siemens Powermite MZ series actuators, providing a minimum of 200 N (45 lb) thrust for reliable operation.
- Standardized Fit: Features 3/4 inch NPT female threads for standard piping integration without specialized adapters.
- Leakage Protection: Achieves Class IV leakage rating, ensuring tight shut-off and improved system efficiency.
Common Questions
Can this valve be used for steam applications?
No, the 599-01138 with brass trim is rated for water and water-glycol solutions. For steam applications, a stainless steel trim variant is typically required.
What is the maximum glycol concentration allowed?
This valve is compatible with water-glycol mixtures up to a 50% concentration without degrading the EPDM O-ring seals.
Which actuators are compatible with the 599-01138?
It is designed for use with Siemens SSB series electronic actuators, which provide the required 7/32-inch (5.5 mm) stroke for full modulation.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
