Siemens Building Technology 588-100A Cable
The Copeland ZP31K5E-PFV-800 is an industry-standard R-410A scroll compressor designed for high-efficiency residential and light commercial air conditioning applications. Delivering 31,100 BTU/HR, this 2.5-ton nominal capacity unit features 1.8 cu-in/rev displacement and operates on 208/230V single-phase power. Engineered with the 5th generation ZPK5 platform, it utilizes a permanent split capacitor motor with internal inherent protection to handle fluctuating thermal loads without premature failure. The POE oil charge ensures proper lubrication for HFC refrigerants, while the 1/2-inch discharge and 3/4-inch suction stub connections allow for direct brazing into existing line sets. With 70% fewer moving parts than reciprocating models, this Copeland scroll compressor provides the reliable start-up performance and high EER ratings required for modern 13+ SEER systems.
Key Benefits- High-Efficiency Performance: Achieves a nominal 10.1 EER, helping systems meet strict energy standards.
- R-410A Compatibility: Optimized specifically for high-pressure HFC refrigerants and POE-AK/DA oil environments.
- Quiet Operation: Designed with a 68-73 dBA sound level, significantly quieter than traditional piston-style compressors.
- Contractor-Ready Package: The 800-series bill of materials includes a 42-inch molded plug wiring harness and mounting hardware for faster field installation.
- Rugged Reliability: Features internal pressure relief valves and inherent motor protection to prevent damage during liquid slugging or high-discharge temperature events.
What is the maximum operating amperage for the ZP31K5E-PFV-800?
This compressor has a Rated Load Amperage (RLA) of 13.5A and a Maximum Operating Current of 17.8A. Technicians should verify that the existing circuit breaker and wire gauge are rated for a minimum circuit ampacity of 26A.
Does this unit require a start capacitor?
While the scroll technology allows it to start under most system loads without assist components, a run capacitor (typically 45-50 MFD/370V ??? 440V) is required for operation but not included in the 800-series kit.
Can I use this as a direct replacement for older ZP31K5E models?
Yes, the ZP31K5E-PFV-800 is the standard service replacement. Always check the suction and discharge line sizes (3/4" and 1/2" stubs) and the 7.5" x 7.5" mounting footprint to ensure fitment within the condensing unit cabinet.
This item is not eligible for free shipping.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
Siemens Building Technology 588-100A Cable
The Copeland ZP31K5E-PFV-800 is an industry-standard R-410A scroll compressor designed for high-efficiency residential and light commercial air conditioning applications. Delivering 31,100 BTU/HR, this 2.5-ton nominal capacity unit features 1.8 cu-in/rev displacement and operates on 208/230V single-phase power. Engineered with the 5th generation ZPK5 platform, it utilizes a permanent split capacitor motor with internal inherent protection to handle fluctuating thermal loads without premature failure. The POE oil charge ensures proper lubrication for HFC refrigerants, while the 1/2-inch discharge and 3/4-inch suction stub connections allow for direct brazing into existing line sets. With 70% fewer moving parts than reciprocating models, this Copeland scroll compressor provides the reliable start-up performance and high EER ratings required for modern 13+ SEER systems.
Key Benefits- High-Efficiency Performance: Achieves a nominal 10.1 EER, helping systems meet strict energy standards.
- R-410A Compatibility: Optimized specifically for high-pressure HFC refrigerants and POE-AK/DA oil environments.
- Quiet Operation: Designed with a 68-73 dBA sound level, significantly quieter than traditional piston-style compressors.
- Contractor-Ready Package: The 800-series bill of materials includes a 42-inch molded plug wiring harness and mounting hardware for faster field installation.
- Rugged Reliability: Features internal pressure relief valves and inherent motor protection to prevent damage during liquid slugging or high-discharge temperature events.
What is the maximum operating amperage for the ZP31K5E-PFV-800?
This compressor has a Rated Load Amperage (RLA) of 13.5A and a Maximum Operating Current of 17.8A. Technicians should verify that the existing circuit breaker and wire gauge are rated for a minimum circuit ampacity of 26A.
Does this unit require a start capacitor?
While the scroll technology allows it to start under most system loads without assist components, a run capacitor (typically 45-50 MFD/370V ??? 440V) is required for operation but not included in the 800-series kit.
Can I use this as a direct replacement for older ZP31K5E models?
Yes, the ZP31K5E-PFV-800 is the standard service replacement. Always check the suction and discharge line sizes (3/4" and 1/2" stubs) and the 7.5" x 7.5" mounting footprint to ensure fitment within the condensing unit cabinet.
This item is not eligible for free shipping.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
