Siemens Building Technology 193-217 Thermostat
The Siemens Building Technology 193-217 Thermostat is a high-performance pneumatic room thermostat engineered for precise temperature regulation in demanding commercial HVACR environments. This dual setpoint sensor controller utilizes Powerstar Free Energy Band technology to optimize energy consumption by providing a "deadband" where the system remains idle between heating and cooling cycles. Designed for two-pipe configurations, it operates with reverse acting (R/A) logic for heating and direct acting (D/A) logic for cooling. The unit features built-in bimetal sensing elements that modulate control air through a flapper nozzle, ensuring a proportional output signal for stable control of pneumatic valves and damper actuators. With a standard 18 to 25 psi supply pressure range and a field-adjustable sensitivity of 1 to 4 psi/°F, this Powerstar thermostat is the industry standard for contractors maintaining building automation systems that require reliable auto-changeover functionality.
Key Benefits- Enhanced Energy Efficiency: The 4°F integrated deadband prevents simultaneous heating and cooling, reducing utility costs.
- Versatile Control Logic: Features Heat-R/A and Cool-D/A dual setpoint capability for multi-stage pneumatic applications.
- Field Serviceable Design: Includes an accessible test port for control pressure verification without removing the cover, streamlining maintenance.
- Standardized Installation: Ships with a wall plate and mounting screws for seamless integration into existing 192/193 series rough-in boxes.
- Precision Hardware: Equipped with integral limit stops to prevent setpoint tampering and protect system integrity.
- What air supply is required for the 193-217? This unit requires clean, dry pneumatic air at a normal pressure of 18 to 25 psi.
- Does this model support both heating and cooling? Yes, it is an auto-changeover dual setpoint thermostat designed for systems requiring separate heating (reverse acting) and cooling (direct acting) signals.
- Can I adjust the deadband in the field? Yes, the two setpoint dials allow for field adjustment of the deadband to a minimum of 4°F.
This item is not eligible for free shipping.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
