Siemens Building Technology 192-207 Stat
The Siemens Building Technology 192-207 is a heavy-duty pneumatic room thermostat designed for high-performance heating and cooling management in 2-pipe commercial systems. Engineered for precision, this direct acting (DA/DA) controller utilizes a sensitive bimetal element to provide proportional dual setpoint regulation. Standard factory settings include a changeover pressure range of 18 to 25 psi, ensuring seamless switching between seasonal modes. This Powerstar 192 series model features a single output with high air capacity, making it compatible with a wide array of pneumatic valves and damper actuators without requiring additional boosters. The integrated 45 to 85°F scale allows for fine-tuned environmental control in institutional facilities. Built with an internal relay for rapid response and minimal air consumption, the 192-207 Stat includes a wall mounting plate and 5/32" hose connectors for straightforward installation in standard terminal boxes. Its field-adjustable limit stops and test port allow technicians to verify output pressure and calibration without removing the desert beige cover, maintaining efficiency in the field.
- Efficient Dual Action: Features independent direct acting heating and cooling setpoints for precise 2-pipe system changeover.
- High Capacity Output: Integral relay supports large volume air delivery for multiple actuators and valves.
- Field Serviceability: Includes a dedicated test port and replaceable filters, thermometers, and restrictors to maximize HVAC pneumatic system longevity.
- Reliable Calibration: Sensitive bimetal responds to 0.1°F changes with factory calibration set at 7.5 psi at 72°F.
Common Questions
How do you adjust the changeover pressure for the 192-207?
The changeover point is factory set between 19 and 22 psi but is field-adjustable between 14 and 22 psi. Technicians can access the adjustment screw by removing the thermometer and using a standard 1/16-inch hex key.
Is this thermostat compatible with 1-pipe systems?
No, the 192-207 is specific to 2-pipe configurations. It requires a dedicated supply air line and a return/control line to function correctly with high-capacity pneumatic loads.
Can I calibrate this unit without specialized tools?
Calibration requires a pneumatic gauge to verify the branch pressure at the test port. For accurate setpoint alignment, use a 192-633 test probe gauge to measure the 7.5 psi output while the ambient temperature matches the dial setting.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
Original: $223.06
-65%$223.06
$78.07Siemens Building Technology 192-207 Stat
The Siemens Building Technology 192-207 is a heavy-duty pneumatic room thermostat designed for high-performance heating and cooling management in 2-pipe commercial systems. Engineered for precision, this direct acting (DA/DA) controller utilizes a sensitive bimetal element to provide proportional dual setpoint regulation. Standard factory settings include a changeover pressure range of 18 to 25 psi, ensuring seamless switching between seasonal modes. This Powerstar 192 series model features a single output with high air capacity, making it compatible with a wide array of pneumatic valves and damper actuators without requiring additional boosters. The integrated 45 to 85°F scale allows for fine-tuned environmental control in institutional facilities. Built with an internal relay for rapid response and minimal air consumption, the 192-207 Stat includes a wall mounting plate and 5/32" hose connectors for straightforward installation in standard terminal boxes. Its field-adjustable limit stops and test port allow technicians to verify output pressure and calibration without removing the desert beige cover, maintaining efficiency in the field.
- Efficient Dual Action: Features independent direct acting heating and cooling setpoints for precise 2-pipe system changeover.
- High Capacity Output: Integral relay supports large volume air delivery for multiple actuators and valves.
- Field Serviceability: Includes a dedicated test port and replaceable filters, thermometers, and restrictors to maximize HVAC pneumatic system longevity.
- Reliable Calibration: Sensitive bimetal responds to 0.1°F changes with factory calibration set at 7.5 psi at 72°F.
Common Questions
How do you adjust the changeover pressure for the 192-207?
The changeover point is factory set between 19 and 22 psi but is field-adjustable between 14 and 22 psi. Technicians can access the adjustment screw by removing the thermometer and using a standard 1/16-inch hex key.
Is this thermostat compatible with 1-pipe systems?
No, the 192-207 is specific to 2-pipe configurations. It requires a dedicated supply air line and a return/control line to function correctly with high-capacity pneumatic loads.
Can I calibrate this unit without specialized tools?
Calibration requires a pneumatic gauge to verify the branch pressure at the test port. For accurate setpoint alignment, use a 192-633 test probe gauge to measure the 7.5 psi output while the ambient temperature matches the dial setting.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
