Siemens Building Technology 192-205 Thermostat
The Siemens Building Technology 192-205 Thermostat is a professional-grade pneumatic dual setpoint thermostat engineered for precise temperature control in commercial HVACR environments. This Powerstar 192 series device operates on a reverse acting (RA) control logic for both day and night modes, specifically designed to modulate pneumatic valves and damper actuators. Utilizing high-sensitivity bi-metal sensing elements, the unit ensures a rapid response to temperature fluctuations between 55 and 85 degrees Fahrenheit. It supports a two-pipe high air capacity configuration and facilitates automatic setpoint transitions when the main air supply pressure shifts between 18 psi (day) and 25 psi (night). This reverse acting pneumatic thermostat is built for efficiency, featuring field-adjustable sensitivity and integral limit stops to prevent setpoint tampering. Its high-flow pneumatic control design provides excellent reliability for retrofit or new installation applications, maintaining consistent environmental conditions while offering an integrated manual override for temporary day-mode operations during unoccupied hours.
Key Benefits- Dual Setpoint Capability: Allows for seamless energy management by switching between occupied and unoccupied temperatures based on supply air pressure.
- Manual Override Feature: Permits occupants to temporarily restore day-mode comfort settings without permanently changing the night schedule.
- Enhanced Precision: Features field-adjustable sensitivity (1 to 4 psi/°F) and a sensitive bi-metal element for accurate thermal tracking.
- Ease of Maintenance: Includes a front-accessible control pressure test port, allowing for calibration and troubleshooting without removing the thermostat cover.
- Durable Construction: Designed for industrial longevity with standard 5/32-inch barb connections for pneumatic air lines.
How does this thermostat switch between day and night modes?
The unit relies on the main supply air pressure. When the system air pressure is at 18 psi, the thermostat operates on the "Day" dial; increasing the main pressure to 25 psi automatically shifts the internal logic to the "Night" dial.
Can the sensitivity be adjusted in the field?
Yes, each mode has a graduated scale for individual field-adjustable sensitivity, typically factory-set at 2.5 psi/°F but customizable to match specific system requirements.
Is the cover included with the 192-205 chassis?
This specific part number generally refers to the thermostat chassis and wall plate; replacement covers in desert beige or white are typically sourced separately depending on the preferred adjustment type (exposed vs. concealed).
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
