Siemens Building Technology 184-112 Restrictor
The Siemens 184-112 is a precision-engineered 10 SCIM tee restrictor designed for critical pneumatic control calibration. Sold as a 5-pack, these components are essential for maintaining stable air pressure in pneumatic circuits, specifically used to balance signals between controllers and actuators. These restrictors utilize a precise orifice to regulate airflow at 10 standard cubic inches per minute (SCIM), ensuring consistent timing and response throughout the HVAC pneumatic system. The Tee-style configuration allows for seamless integration into 1/4" OD polyethylene tubing setups without the need for additional manifold blocks. Engineered for durability in high-demand mechanical rooms, these restrictors prevent rapid oscillations in pneumatic actuators and valves by providing a controlled leak rate or pilot signal stabilization. For service technicians performing maintenance on legacy pneumatic panels, these Siemens components offer a direct fit for 184 series pneumatic accessories, ensuring reliable performance across the control loop.
Key Technical Benefits- Precision Flow Control: Calibrated to 10 SCIM for accurate pneumatic signal regulation.
- Contractor 5-Pack: Provides cost-effective inventory for large-scale facility maintenance.
- Tee-Style Design: Simplifies installation by allowing direct multi-point connections in 1/4" lines.
- System Stability: Minimizes signal hunting and actuator chatter in legacy pneumatic systems.
- Compatibility: Designed for integration with Siemens and Landis & Gyr pneumatic controllers.
What is the primary function of a 10 SCIM restrictor in a pneumatic loop?
It provides a constant, controlled airflow rate to create a predictable pressure drop, typically used to provide a pilot air supply to a transmitter or relay.
Are these restrictors compatible with 5/32" pneumatic tubing?
The Siemens 184-112 is standard for 1/4" OD tubing; adaptation for 5/32" lines would require specific reducers to maintain the integrity of the pressure signal.
How can I identify if the restrictor orifice is clogged?
If the pneumatic actuator fails to respond or the signal pressure remains static regardless of controller output, the restrictor orifice should be checked for debris or oil contamination.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
