Omron PTFZ08E Relay Socket
The Omron PTFZ08E Relay Socket is a high-reliability 8-pin relay base designed for front-mount applications in industrial control panels and HVACR systems. As a 1:1 direct replacement for PTF08A-E, this track-mounted socket maintains full physical and electrical compatibility with Omron LY series power relays, specifically the LY1 and LY2 DPDT models. For veteran technicians managing retrofits or new installations, this socket features finger-safe screw terminals with captive wire clamps, ensuring secure DIN rail mounting and consistent conductivity under high-vibration conditions.
Engineered for professional-grade performance, the Omron PTFZ08E supports a rated carry current up to 15A at 50°C (12A at 70°C) and a dielectric strength of 2,500 VAC between coil and contacts. Its robust polyphenylene construction provides an insulation resistance of 1,000 M? minimum. This 8-position terminal socket is optimized for control panel wiring, accepting up to two 12 AWG wires or forked crimp terminals. This component ensures a stable interface for general-purpose switching, energy management, and industrial machine control applications without requiring mechanical modifications to existing relay mounting layouts.
Key Benefits- Full Backward Compatibility: Serves as the official successor to the PTF08A-E, fitting identical mounting holes and terminal arrangements.
- Enhanced Safety: Finger-safe architecture (E-model structure) prevents accidental contact with live electrical components during maintenance.
- High Current Rating: Handles up to 15A, making it suitable for heavy-duty HVACR switching loads and power relay operations.
- Versatile Installation: Dual-purpose design allows for rapid DIN rail snapping or secure surface mounting via standard M3.5 screw connections.
- Refined Connection Stability: Features captive wire clamps and forked terminal compatibility to prevent wire slippage and carbon tracking.
Is the PTFZ08E compatible with my old LY2 series relays?
Yes. This socket is specifically designed to house Omron LY1 and LY2 series relays. It maintains the same 8-pin square layout as the discontinued PTF08A-E, allowing for a seamless drop-in replacement.
Can I use round crimp terminals with this socket?
No. To maintain the finger-safe protection rating, this model is designed for use with forked crimp terminals or bare wire. Round terminals will not seat properly within the protected screw architecture.
Does this socket include the hold-down clips?
Hold-down clips (such as the Y92H-3 for LY relays) are typically sold separately and are not included with the base socket unless specified. This allows technicians to select the specific clip required for their relay height and vibration environment.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
Omron PTFZ08E Relay Socket
The Omron PTFZ08E Relay Socket is a high-reliability 8-pin relay base designed for front-mount applications in industrial control panels and HVACR systems. As a 1:1 direct replacement for PTF08A-E, this track-mounted socket maintains full physical and electrical compatibility with Omron LY series power relays, specifically the LY1 and LY2 DPDT models. For veteran technicians managing retrofits or new installations, this socket features finger-safe screw terminals with captive wire clamps, ensuring secure DIN rail mounting and consistent conductivity under high-vibration conditions.
Engineered for professional-grade performance, the Omron PTFZ08E supports a rated carry current up to 15A at 50°C (12A at 70°C) and a dielectric strength of 2,500 VAC between coil and contacts. Its robust polyphenylene construction provides an insulation resistance of 1,000 M? minimum. This 8-position terminal socket is optimized for control panel wiring, accepting up to two 12 AWG wires or forked crimp terminals. This component ensures a stable interface for general-purpose switching, energy management, and industrial machine control applications without requiring mechanical modifications to existing relay mounting layouts.
Key Benefits- Full Backward Compatibility: Serves as the official successor to the PTF08A-E, fitting identical mounting holes and terminal arrangements.
- Enhanced Safety: Finger-safe architecture (E-model structure) prevents accidental contact with live electrical components during maintenance.
- High Current Rating: Handles up to 15A, making it suitable for heavy-duty HVACR switching loads and power relay operations.
- Versatile Installation: Dual-purpose design allows for rapid DIN rail snapping or secure surface mounting via standard M3.5 screw connections.
- Refined Connection Stability: Features captive wire clamps and forked terminal compatibility to prevent wire slippage and carbon tracking.
Is the PTFZ08E compatible with my old LY2 series relays?
Yes. This socket is specifically designed to house Omron LY1 and LY2 series relays. It maintains the same 8-pin square layout as the discontinued PTF08A-E, allowing for a seamless drop-in replacement.
Can I use round crimp terminals with this socket?
No. To maintain the finger-safe protection rating, this model is designed for use with forked crimp terminals or bare wire. Round terminals will not seat properly within the protected screw architecture.
Does this socket include the hold-down clips?
Hold-down clips (such as the Y92H-3 for LY relays) are typically sold separately and are not included with the base socket unless specified. This allows technicians to select the specific clip required for their relay height and vibration environment.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
