Omron LY2FDC-24 Relay
The Omron LY2F-DC24 is a professional-grade DPDT power relay engineered for demanding HVACR control circuits and industrial automation. Featuring a 24VDC coil voltage and an 8-pin configuration, this miniature power relay is designed for surface or flange mounting, providing secure installation in high-vibration environments. The DPDT (2 Form C) contact form supports high-capacity switching up to 10A, making it ideal for managing inductive loads, motor starters, and solenoid valves. Built with high dielectric strength and superior insulation resistance, the LY2FDC24 ensures stable performance during continuous duty cycles. This 24VDC 8-pin relay utilizes silver alloy contacts to minimize contact resistance and prevent pitting, ensuring reliable mechanical switching over the life of the component. For contractors requiring a robust general-purpose relay with a compact footprint, this Omron model provides the necessary specifications for precise electrical isolation and load management in complex control strings.
Key Benefits for HVACR Applications- High Switching Capacity: Rated for up to 10A, handling standard HVAC control circuit loads with ease.
- DPDT Contact Configuration: Allows for simultaneous control of two separate circuits or polarity reversal.
- Integrated Flange Mount: Simplifies installation in panels without the need for additional DIN rail sockets.
- DC Coil Efficiency: The 24VDC coil draws minimal power while providing high magnetic force for reliable contact engagement.
- Rugged Construction: Designed to withstand the thermal cycling and electrical noise common in mechanical rooms.
What is the difference between the LY2 and LY2F series?
The "F" suffix indicates a flange-mounted housing. While the internal electrical specifications of the Omron LY2 relay remain the same, the LY2F allows for direct screw-mounting to a backplate, whereas standard LY models are typically intended for socket mounting.
Can this relay handle inductive motor loads?
Yes, the LY2F-DC24 is rated for inductive loads, though current derating should be calculated based on the specific horsepower or LRA (Locked Rotor Amps) of the motor being controlled.
Is the coil polarity sensitive?
Standard DC models are not polarity sensitive unless they include an integrated LED indicator or diode suppression. Always verify the specific terminal diagram on the relay housing before wiring 24VDC power.
