Nordyne M0092718R Motor
The Copeland ZP31K5E-PFV-830 is a high-efficiency 2.5 ton scroll compressor engineered specifically for R-410A air conditioning and heat pump systems. As a 5th generation ZPK5 fixed-speed model, this unit delivers a nominal capacity of 31,100 BTU/HR at standard rating conditions. This single-phase HVAC compressor operates on 208-230V at 60Hz and features a Permanent Split Capacitor (PSC) motor with internal inherent protection to prevent thermal overload. Designed for standard sweat connections, the suction line is 3/4" and the discharge line is 1/2", making it a direct drop-in for many residential condensing units. This unit utilizes 25 oz of POE oil for superior lubrication and features a centrifugal oil pump to ensure consistent performance across high-temperature applications. With a Locked Rotor Amps (LRA) rating of 79.0 and a Maximum Continuous Current (MCC) of 26.0A, this compressor provides the reliability expected by veteran contractors for critical system restorations.
Key Benefits- High-Efficiency Performance: Achieves an 11.0+ EER rating for reduced energy consumption in residential AC units.
- Quiet Operation: Designed with smooth scroll movement to minimize sound power levels down to 68-73 dBA.
- Enhanced Reliability: Internal inherent motor protection and a rugged scroll design reduce vibration and mechanical wear.
- Simplified Installation: Features standard 7.5" x 7.5" mounting footprints and includes a molded plug wiring harness for faster field replacement.
What is the correct run capacitor for the ZP31K5E-PFV-830?
This model requires a 45 µF / 370V run capacitor for optimal motor phase alignment and torque.
Is this compressor compatible with R-22 systems?
No, this model is designed strictly for R-410A refrigerant and uses Polyolester (POE) oil, which is not compatible with mineral oil systems.
Can I use this for a heat pump application?
Yes, the ZP31K5E-PFV-830 is rated for both high-temp air conditioning and heat pump duty cycles.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
