Nidec-US Motors 1891 Motor
This Honeywell VR8304M4507 is a 24 VAC dual automatic intermittent pilot gas valve, engineered for high-capacity heating applications up to 300,000 BTU/hr (415 CFH). As a standard-opening, straight-through body control, it provides the reliability needed for furnace gas valve replacement in demanding commercial and residential environments. The unit features 3/4 in. x 3/4 in. NPT inlet/outlet connections and is specifically designed for use with S8600, S8610, and S90 series intermittent pilot ignition modules. A field-proven adjustable servo regulator maintains consistent manifold pressure even during wild fluctuations in line pressure, ensuring stable gas furnace burner combustion. To maximize installer flexibility, the valve includes secondary reducer bushings for 1/2 in. pipe and a natural to LP gas conversion kit. All wiring terminals and pressure taps are top-accessible, simplifying the diagnosis of HVAC system pressure issues and allowing for mounting up to 90 degrees in any direction from the upright position.
Key Benefits
- High Capacity Performance: Handles up to 300,000 BTU/hr with a 1 in. wc pressure drop, suitable for powerful central heating units.
- Dual Safety Shutoff: Features two automatic operators (solenoid and diaphragm) to meet strict safety codes for fuel gas control.
- Field Versatility: Includes an LP conversion kit and two 3/4 in. x 1/2 in. reducer bushings to fit various piping configurations.
- Contractor-Friendly Design: All adjustments, including the pilot flow and servo regulator, are accessible from the top of the control.
- Extreme Durability: Rated for a wide ambient temperature range of -40°F to +175°F, ensuring operation in unconditioned spaces.
Common Questions
Is this a direct replacement for my current intermittent pilot valve?
This model is a primary choice for Honeywell gas valve troubleshooting when replacing VR8304 or VR8204 series controls. Always verify your module compatibility (S8600/S8610) and inlet/outlet sizing before installation.
Can I use this valve for a liquid propane (LP) application?
Yes. While factory-set for natural gas at 3.5 in. wc, the package contains the necessary LP gas conversion kit to modify the regulator for 10.0 in. wc propane operation.
What ignition systems are compatible with the VR8304M4507?
It is built strictly for intermittent pilot ignition systems. It is not designed for standing pilot or direct spark ignition (DSI) configurations.
This item is not eligible for free shipping.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
Original: $322.13
-65%$322.13
$112.75Nidec-US Motors 1891 Motor
This Honeywell VR8304M4507 is a 24 VAC dual automatic intermittent pilot gas valve, engineered for high-capacity heating applications up to 300,000 BTU/hr (415 CFH). As a standard-opening, straight-through body control, it provides the reliability needed for furnace gas valve replacement in demanding commercial and residential environments. The unit features 3/4 in. x 3/4 in. NPT inlet/outlet connections and is specifically designed for use with S8600, S8610, and S90 series intermittent pilot ignition modules. A field-proven adjustable servo regulator maintains consistent manifold pressure even during wild fluctuations in line pressure, ensuring stable gas furnace burner combustion. To maximize installer flexibility, the valve includes secondary reducer bushings for 1/2 in. pipe and a natural to LP gas conversion kit. All wiring terminals and pressure taps are top-accessible, simplifying the diagnosis of HVAC system pressure issues and allowing for mounting up to 90 degrees in any direction from the upright position.
Key Benefits
- High Capacity Performance: Handles up to 300,000 BTU/hr with a 1 in. wc pressure drop, suitable for powerful central heating units.
- Dual Safety Shutoff: Features two automatic operators (solenoid and diaphragm) to meet strict safety codes for fuel gas control.
- Field Versatility: Includes an LP conversion kit and two 3/4 in. x 1/2 in. reducer bushings to fit various piping configurations.
- Contractor-Friendly Design: All adjustments, including the pilot flow and servo regulator, are accessible from the top of the control.
- Extreme Durability: Rated for a wide ambient temperature range of -40°F to +175°F, ensuring operation in unconditioned spaces.
Common Questions
Is this a direct replacement for my current intermittent pilot valve?
This model is a primary choice for Honeywell gas valve troubleshooting when replacing VR8304 or VR8204 series controls. Always verify your module compatibility (S8600/S8610) and inlet/outlet sizing before installation.
Can I use this valve for a liquid propane (LP) application?
Yes. While factory-set for natural gas at 3.5 in. wc, the package contains the necessary LP gas conversion kit to modify the regulator for 10.0 in. wc propane operation.
What ignition systems are compatible with the VR8304M4507?
It is built strictly for intermittent pilot ignition systems. It is not designed for standing pilot or direct spark ignition (DSI) configurations.
This item is not eligible for free shipping.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
