Multi Products 5519E Motor Actuator
Identify and replace aging damper controls with the Multi Products 5519E Motor Actuator, a precision-engineered 120V AC motor designed for heavy-duty HVAC and industrial automation. This clockwise (CW) rotation actuator serves as the dedicated direct replacement for Multi Products 1519E, ensuring seamless mechanical compatibility without the need for extensive field modifications. Built within a rugged zinc die-cast housing, the 5519E utilizes a high-torque geartrain to provide consistent 37 in-lb stall torque, making it ideal for managing large dampers and airflow shutters that require reliable rotational force.
For service technicians and contractors, the Multi Products 5519E is the standard for long-term performance in intermittent duty cycles. Its shaded pole motor design minimizes wear parts, providing a stable 2-3 RPM output speed even under varying mechanical loads. Whether you are performing a damper motor replacement or upgrading a shutter motor actuator, this genuine OEM replacement ensures your system maintains its original engineering specifications and operational efficiency.
Key Benefits for Technicians- OEM Compatibility: Engineered as the primary 5519E replacement for 1519E and 1519D models.
- High Torque Output: Delivers 37 in-lb stall torque to handle demanding mechanical resistance in industrial dampers.
- Durable Construction: Features a dust-proof zinc die-cast housing and heavy-duty metal geartrain for harsh mechanical environments.
- Standardized Power: Operates on 120V AC, the standard voltage for commercial and residential ventilation systems.
- Compact Profile: Designed for tight installations in HVAC actuator housings and automation enclosures.
Is the 5519E compatible with my old 1519E motor?
Yes, the Multi Products 5519E is the official successor and direct replacement for the 1519E and 1519D series. It maintains the same mounting footprint and 120V electrical requirements.
What does 'CW Rotation' signify for this actuator?
This motor is fixed for Clockwise (CW) rotation. When looking at the output shaft, the movement will always travel clockwise. Before purchasing, verify that your damper or shutter assembly requires CW rotation to prevent mechanical binding.
Can this motor be used for continuous duty?
While the 5519E is robustly built, it is optimized for intermittent duty applications typically found in damper and ventilation control. For continuous 24/7 rotation, consult the manufacturer's load charts.
This item is not eligible for free shipping.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
