Lochinvar & A.O. Smith 100277815 Connection Board
The Lochinvar & A.O. Smith 100277815 Connection Board is a critical low-voltage interface designed for precise communication between the Smart System control and external HVAC components. As a veteran-grade low voltage connection board, it serves as the central hub for integrating 0-10 VDC BMS inputs, building alarm contacts, and multi-unit cascade sequencing. This OEM boiler control board is engineered to handle signal routing for pump delays, freeze protection sensors, and water heater diagnostics, ensuring the master controller maintains tight firing rate modulation across the header.
For technicians performing a control board replacement, the 100277815 provides a stable terminal architecture to prevent signal noise in high-recovery copper-fin systems. Whether you are troubleshooting a Lochinvar 100 125 065 model or an A.O. Smith equivalent, this board is the primary interface for 120V/24V logic separation. Replacing a compromised interface restores full automated functionality to the HVAC zone control board, allowing for seamless rotation and stage firing in high-demand commercial and residential applications.
Key Benefits- System Integration: Provides dedicated terminals for 0-10 VDC BMS control and external low voltage devices.
- Cascade Reliability: Facilitates the built-in cascade logic to sequence up to eight units for optimized load distribution.
- Diagnostic Clarity: Maintains the integrity of sensor data sent to the 2-line LCD display for accurate water heater troubleshooting.
- Rugged Design: Built to withstand the thermal environments of sealed combustion chambers and high-cycle operations.
What are the signs that a connection board is failing?
Common indicators include intermittent loss of BMS communication, "Communication Error" faults on the Smart System display, or the failure of external pumps to trigger during the post-purge cycle.
Is this board compatible with both Lochinvar and A.O. Smith units?
Yes, the 100277815 is a versatile OEM part used across both brands, specifically in Copper-Fin II and high-efficiency commercial water heater models utilizing the Smart System platform.
Does this board handle high voltage power switching?
No, this is a low voltage connection board. It manages logic and signaling; high-voltage loads are typically handled by integrated relays or the main CCB.
This item is not eligible for free shipping.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
Lochinvar & A.O. Smith 100277815 Connection Board
The Lochinvar & A.O. Smith 100277815 Connection Board is a critical low-voltage interface designed for precise communication between the Smart System control and external HVAC components. As a veteran-grade low voltage connection board, it serves as the central hub for integrating 0-10 VDC BMS inputs, building alarm contacts, and multi-unit cascade sequencing. This OEM boiler control board is engineered to handle signal routing for pump delays, freeze protection sensors, and water heater diagnostics, ensuring the master controller maintains tight firing rate modulation across the header.
For technicians performing a control board replacement, the 100277815 provides a stable terminal architecture to prevent signal noise in high-recovery copper-fin systems. Whether you are troubleshooting a Lochinvar 100 125 065 model or an A.O. Smith equivalent, this board is the primary interface for 120V/24V logic separation. Replacing a compromised interface restores full automated functionality to the HVAC zone control board, allowing for seamless rotation and stage firing in high-demand commercial and residential applications.
Key Benefits- System Integration: Provides dedicated terminals for 0-10 VDC BMS control and external low voltage devices.
- Cascade Reliability: Facilitates the built-in cascade logic to sequence up to eight units for optimized load distribution.
- Diagnostic Clarity: Maintains the integrity of sensor data sent to the 2-line LCD display for accurate water heater troubleshooting.
- Rugged Design: Built to withstand the thermal environments of sealed combustion chambers and high-cycle operations.
What are the signs that a connection board is failing?
Common indicators include intermittent loss of BMS communication, "Communication Error" faults on the Smart System display, or the failure of external pumps to trigger during the post-purge cycle.
Is this board compatible with both Lochinvar and A.O. Smith units?
Yes, the 100277815 is a versatile OEM part used across both brands, specifically in Copper-Fin II and high-efficiency commercial water heater models utilizing the Smart System platform.
Does this board handle high voltage power switching?
No, this is a low voltage connection board. It manages logic and signaling; high-voltage loads are typically handled by integrated relays or the main CCB.
This item is not eligible for free shipping.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
