Lennox 97W45 Limit Switch
The Lennox 97W45 Limit Switch is a critical safety component designed for precise thermal regulation within residential gas furnaces and air handlers. Engineered as a normally closed thermal switch, this L140-30F secondary limit monitors heat exchanger temperatures to prevent overheating and potential heat exchanger fatigue. With a fixed temperature setting of 140°F and a 30°F differential, this Lennox high limit sensor ensures a reliable cutout when temperatures exceed safe operating parameters, automatically resetting once the system cools. This genuine OEM Lennox replacement part is essential for maintaining furnace safety standards and ensuring proper sequencing of the combustion cycle. For HVAC contractors, the 97W45 provides a direct-fit solution for Lennox furnace repair, featuring standard 1/4-inch spade terminals for rapid integration into existing wiring harnesses. Proper installation of this internal furnace safety switch is vital for preventing nuisance tripping and maintaining system uptime during high-demand heating cycles.
Key Benefits for Technicians- Precise Thermal Calibration: Calibrated for a 140-degree trip point to protect the heat exchanger from high-temperature excursions.
- Direct OEM Compatibility: Ensures seamless integration with Lennox gas furnace control circuits without the need for mounting modifications.
- Automatic Reset Functionality: Features a 30-degree differential reset, allowing the system to resume operation once safe temperatures are restored.
- Durable Construction: Built to withstand the high-cycle environment of a furnace cabinet, reducing the risk of premature component failure.
What causes a Lennox 97W45 limit switch to trip repeatedly?
Frequent tripping is usually indicative of restricted airflow, often caused by a dirty air filter, blocked return air ducts, or a failing blower motor. If the switch trips and does not reset, it may have failed due to internal resistance.
Can I use a universal limit switch instead of the 97W45?
While universal switches exist, using the specific Lennox 97W45 L140-30F switch is recommended to ensure the temperature profile and reset differential match the original equipment manufacturer's safety specifications.
How do I verify if the 97W45 limit switch is defective?
Disconnect the power and check for continuity across the terminals. At room temperature, the switch should be closed (0 ohms). if the circuit is open while the furnace is cool, the switch requires replacement.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
