iO HVAC Controls RY-1-HB Relay
The iO HVAC Controls RY-1-HB Relay is a high-reliability 24 Vac SPDT relay designed for seamless integration into standard handy boxes or snap track mounting environments. Built for professional HVACR applications, this 15 Amp SPDT relay features a rugged printed circuit board with wave-soldered components to ensure long-term mechanical stability in high-vibration settings. The RY-1-HB serves as a critical component for general purpose HVAC switching, commonly utilized in twinning kits or as a necessary interface for the iO-WR-XR extended range wireless relay systems. Its 24 volt AC/DC coil and 10 Amp rated contacts provide the versatility needed for isolation, pilot duty, or controlling auxiliary equipment. Contractors will value the functional design, which includes angled terminal strips for easy field wiring and an integrated LED indicator that provides instant visual confirmation of the relay's energized state, drastically reducing troubleshooting time during system startups or maintenance calls.
Key Benefits- Versatile Mounting: Includes snap track for panel installation and is specifically designed for handy box mounting to reduce total enclosure costs.
- Field Diagnostics: Features an onboard LED status indicator allowing technicians to verify relay activation at a glance.
- High Capacity Switching: Equipped with 10 Amp contacts capable of handling heavy-duty pilot or power loads in residential and commercial systems.
- Simplified Wiring: Angled terminal strips provide better access for 18-gauge thermostat wire, ensuring secure terminations in tight spaces.
- Universal Compatibility: Works as a foundational 24V HVAC relay for zoning, twinning, and wireless control expansions.
Can the RY-1-HB be used for twinning non-identical furnaces?
While this relay is used in twinning applications to sync blowers, it is technically recommended to use identical equipment for simultaneous fan starts. If units differ, back-draft dampers should be installed in the ductwork.
Does this relay support both AC and DC control circuits?
Yes, the iO HVAC Controls RY-1-HB features a universal 24 volt AC/DC coil, making it compatible with various control signals found in modern building automation and HVAC systems.
Is the snap track included with the relay?
Yes, the unit comes with a 2.75-inch snap track mount, though it is specifically optimized for installation within a standard electrical handy box.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
