Greenheck CSP-A390 Exhaust Fan
The Greenheck CSP-A390 is a high-performance inline cabinet exhaust fan engineered specifically for technical applications requiring reliable clean air ventilation and low sound levels. This direct drive centrifugal fan features a robust galvanized steel housing lined with acoustic insulation to minimize vibration and noise transfer in commercial ductwork. The forward-curved wheel is balanced for AMCA certified air performance, delivering between 57 and 417 CFM depending on static pressure and motor configuration. Designed for contractor efficiency, the unit includes adjustable mounting brackets, a large electrical junction box, and a square outlet for simplified inline duct mounting. Field-rotatable discharge and easy access panels allow technicians to maintain internal components or adjust the backdraft damper without dismantling the entire run.
Key Benefits for Contactors
- Acoustic Insulation: Built-in lining absorbs operational noise, making it ideal for noise-sensitive indoor environments.
- Flexible Installation: Integrated adjustable mounting brackets and vertical electrical access eliminate the need for field drilling.
- Variable Speed Control: The speed controllable motor allows for precise system balancing and airflow adjustment across various static pressures.
- Rugged Construction: Embossed galvanized steel provides superior rigidity and resistance to workspace wear.
- Compact Footprint: The 14 x 11.875-inch frame fits easily into tight ceiling or wall cavities for clean air exhaust or supply.
Common Questions & Technical Support
Can the Greenheck CSP-A390 be mounted in any orientation?
Yes, while typically assembled for horizontal discharge, these inline fans can be field-rotated to vertical discharge to accommodate specific ducting layouts.
What type of ducting is required for this cabinet fan?
The unit features an 8x8 inch square outlet and 12.875x10 inch inlet, designed to integrate seamlessly with standard rectangular or square HVAC ducting.
Is the motor thermal protection automatic?
Yes, the direct drive motor includes internal thermal protection to safeguard the unit during high-demand or high-static pressure operations.
This item is not eligible for free shipping.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
