Functional Devices TR100VA009 Transformer
The Functional Devices TR100VA009 Transformer is a heavy-duty 96VA power solution engineered for versatile field applications. This multi-tap transformer features a wide input range, supporting 480/277/240/208/120Vac primary voltage, making it a standard stock item for servicing various industrial and commercial HVACR systems. It provides a stable 24Vac secondary voltage output, essential for powering thermostats, zone controllers, and relay boards. For added circuit reliability, it includes integrated circuit breaker over current protection, which allows for quick resets without the need for fuse replacements. This model serves as the direct replacement for PF524100, ensuring zero-latency transitions during repairs. Designed for flexible installation, the unit supports both foot and dual threaded hub mount configurations, allowing it to be secured directly to electrical boxes or equipment chassis. This transformer is built to handle the inductive loads and voltage fluctuations common in demanding automation environments.
Key Benefits
- Universal Compatibility: The multi-tap primary configuration eliminates the need to carry multiple transformers for different site voltages.
- Enhanced Safety: The built-in reset button acts as a reliable overload protection mechanism to prevent coil burnout.
- Rugged Mounting: Dual 1/2-inch NPT hubs and foot mounts provide secure attachment points in high-vibration applications.
- High Power Capacity: Rated at 96VA, providing ample headroom for complex control circuits and multiple solenoid valves.
Common Questions
Can the TR100VA009 be used in plenum spaces?
Yes, its construction and hub-mount design allow for installation within air handling units and electrical enclosures where plenum-rated components are required.
What is the benefit of a 96VA rating over a standard 40VA transformer?
The higher VA rating allows the TR100VA009 to handle a larger total load, preventing voltage drops when multiple 24V components engage simultaneously.
Is this a suitable 480V to 24V step down transformer for commercial RTUs?
Absolutely. Its 480Vac primary tap is specifically designed for integration into commercial rooftop units and industrial control panels.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
