Functional Devices RIBMNU1S Relay
The Functional Devices RIBMNU1S Relay is a professional-grade 15 Amp pilot relay designed for high-reliability switching in BAS, HVAC, and lighting control applications. This track-mounted modular relay features a versatile triple-voltage coil, allowing for seamless integration into systems utilizing 10-30 Vac/Vdc or a standard 120 Vac power source. Engineered for long-term field performance, it utilizes a SPST (Single Pole Single Throw) contact configuration and includes an integrated override switch for manual circuit control during commissioning or maintenance. The unit is optimized for MT212 mounting tracks and includes a high-visibility LED status indicator to confirm relay activation. Designed for technical precision, the RIBMNU1S handles resistive loads up to 15A at 150 Vac and is rated for motor control at 1/3 HP, making it a staple for contractors requiring a compact, versatile solution for multi-voltage environments without the need for additional enclosures.
Key Benefits of the RIBMNU1S Relay:- Multi-Voltage Flexibility: Features a universal coil compatible with 10-30 Vac/dc and 120 Vac, reducing the need to carry multiple specialized relays.
- Manual Override Control: The built-in toggle switch allows for immediate manual testing and system troubleshooting without external jumpers.
- Snap-Track Mounting: Specifically designed for 2.75-inch tracks, enabling high-density installation within HVAC control panels.
- Durable Performance: Rated for up to 10 million mechanical cycles with a broad operating temperature range of -30 to 140°F.
- UL Listed Reliability: Meets UL916 Energy Management and UL864 Fire standards for code-compliant commercial installations.
- What is the maximum amperage for motor loads? The RIBMNU1S is rated for 1/3 HP at 120-240 Vac on the Normally Open (N/O) contacts.
- Does this relay require a specific mounting track? Yes, this module is sized for use with the MT212 Series mounting track.
- Is there a way to verify the relay is energized? Yes, a prominent LED indicator glows when the coil is successfully activated.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
