Danfoss 060-214991 Pressure switch
The Danfoss 060-214991 is a commercial-grade KP 34 pressure switch engineered for regulating and monitoring steam or air systems. This auto reset pressure control operates within a 2 psi to 15 psi range with an adjustable differential of 2 psi to 6 psi. Designed for heavy-duty cycling, the unit features high-load SPDT contact systems (Single Pole Double Throw), ensuring reliable electrical switching even under vibration-prone conditions. This specific model serves as the direct replacement for 060-214966, maintaining the same mounting footprint and 1/4 inch NPT connection for seamless field swaps. The enclosure is rated for IP30, protecting the internal bellows and mechanics from dust and physical contact. Whether managing boiler low-pressure limits or controlling pneumatic systems, the Danfoss KP-34 provides consistent set-point stability and rapid response times required for precise mechanical system management.
Key Benefits for Contractors
- Direct Replacement: Fully compatible drop-in for the legacy Danfoss 060-214966 model, minimizing downtime during retrofits.
- Adjustable Differential: Allows for fine-tuning the 2-6 psi deadband to prevent short-cycling and reduce contact wear.
- Vibration Resistant: The trip-free contact system ensures the switch maintains its state even in high-vibration mechanical rooms.
- Snap-Action Contacts: Rapid switching action reduces arcing and extends the life of the internal electrical components.
- Versatile Media: Suitable for steam, air, and gas applications, providing a single-part solution for multiple job site requirements.
Common Questions
How do I adjust the pressure settings?
The Danfoss 060-214991 uses two separate screws located at the top of the unit: one for the primary pressure range and one for the differential. Use a calibrated gauge during the KP-34 adjustment process to verify the cut-in and cut-out points.
Will this work in high-moisture environments?
The standard enclosure is IP30. While suitable for indoor mechanical rooms, if moisture or heavy washdown is expected, a separate protective cover or higher IP-rated housing should be used to protect the bellows pressure switch mechanism.
What is the maximum working pressure?
The unit is rated for a maximum operating pressure (MWP) of 58 psig and a maximum test pressure of 145 psig to prevent bellows deformation during system pressure tests.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
