Copeland Comfort Control (Alco) 022303 Indicator
The Copeland Comfort Control (Alco) 022303 AMI-2S11 Moisture Indicator is a critical diagnostic component for high-capacity HVACR liquid line monitoring. Engineered with a large 1 3/8" sweat ODF connection and a robust 650 PSI maximum working pressure, this indicator provides technicians with a high-visibility window for real-time assessment of refrigerant state and moisture levels. Utilizing a sophisticated crystal moisture indicator element rather than basic paper indicators, the AMI-2S11 offers superior sensitivity to moisture content as low as 50 ppm. This ensures precise refrigerant color-coded drying identification, allowing contractors to identify HVACR system contamination before acid formation or copper plating causes compressor failure. The hermetic, leak-free construction and corrosion-resistant brass body make it compatible with a full range of CFC, HCFC, and HFC refrigerants, as well as mineral, alkylbenzene, and POE lubricants.
Key Performance Benefits
- Maximum System Sensitivity: Employs a high-accuracy crystal element that reacts to minimal moisture levels, ensuring refrigerant quality control in sensitive commercial systems.
- High-Pressure Durability: Rated for a 650 PSI max working pressure, meeting the rigorous demands of industrial refrigeration and high-pressure air conditioning applications.
- Broad Lubricant Compatibility: Designed for seamless operation with modern POE oils, mineral oils, and alkylbenzene lubricants without degradation of the indicator element.
- Efficient Field Diagnostics: The wide-angle viewing lens allows for a clear visual refrigerant inspection to confirm a full liquid line and the absence of flash gas.
- Contractor-Grade Construction: Features a solid brass body and 1-3/8" ODF solder connections for a permanent, leak-resistant installation in large-diameter piping.
Common Questions
How do I interpret the color change in the AMI-2S11?
The indicator changes from green to yellow based on the moisture content relative to the refrigerant type and temperature. Green indicates a dry system, while Yellow signals that the moisture level has reached a cautionary point, requiring a filter-drier replacement to prevent system damage.
Is the AMI-2S11 compatible with R-410A?
Yes, it is fully compatible with R-410A and other high-pressure HFCs, provided the operating pressure remains within the 650 PSI working pressure limit and standard POE lubricants are used.
Can the lens assembly be serviced?
Yes, the AMI series is designed with a highly serviceable lens assembly. Unlike fully hermetic disposable indicators, the lens and internal indicator element of this model can be exchanged using a lens assembly kit if needed.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
