Carrier HD46AR344 Motor
The Carrier HD46AR344 is a heavy-duty 3/4 HP PSC motor designed for high-static applications in Bryant, Carrier, and Payne furnace and air handler units. This 1050 RPM multi-speed motor features a dual voltage 115/208-230V configuration, making it a versatile field replacement for damaged OEM blowers. Built with an open air over (OAO) enclosure and NEMA 48 frame, it ensures optimal thermal management during continuous operation. The reversible rotation (CW/CCW) capability allows for precise matching of original equipment specifications, while the ball bearing design provides superior durability against radial and axial loads compared to standard sleeve bearings. When replacing this unit, ensure the run capacitor (typically 10MFD/370V) is checked to maintain proper torque and amperage draw within the FLA (Full Load Amps) rating. This OEM Carrier replacement motor is engineered for direct-drive blower assemblies where reliability and precise airflow are critical for system efficiency.
- Dual Voltage Versatility: Supports both 115V and 208-240V installations for broader compatibility with residential and light commercial air handlers.
- High-Torque Performance: The 3/4 HP rating provides the necessary power for multi-speed fan applications requiring consistent 1050 RPM.
- Reversible Rotation: Simplified field configuration with easy-to-swap leads for clockwise or counter-clockwise operation.
- Durable Construction: Features all-angle ball bearings and an OAO enclosure for extended service life in demanding environments.
Common Questions
What capacitor is required for the HD46AR344?
This motor typically requires a 10 MFD / 370V run capacitor. Always verify the rating on the motor nameplate during installation to prevent overheating.
Is this motor compatible with variable speed systems?
No, the HD46AR344 is a Permanent Split Capacitor (PSC) motor. It is designed for multi-speed taps and is not a direct replacement for ECM or constant torque motors.
Can I use this motor to replace a 1/2 HP motor?
While a 3/4 HP motor can handle the load of a 1/2 HP motor, you must ensure the physical frame size (NEMA 48) and shaft diameter match your blower wheel and mounting bracket.
This item is not eligible for free shipping.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
