Carrier 338096-701 Limit Switch
Ensure critical safety and operational reliability in heating systems with the Carrier 338096-701 Limit Switch. This genuine OEM replacement part is engineered for precision temperature monitoring, serving as a primary high-limit safety cut-out for compatible Carrier, Bryant, and Payne furnaces. Designed with an automatic reset function, the switch features a calibrated thermal response that opens the electrical circuit when internal plenum temperatures reach 180°F (82°C) and automatically closes to restore operation once the system cools to 160°F (71°C). This L180-20F limit switch prevents heat exchanger damage and hazardous overheating conditions, making it a vital component for maintaining HVAC system safety. Technical specifications include a SPDT contact configuration and an electrical rating optimized for 24V control circuits. Replacing a faulty or tripped furnace limit switch with a factory-authorized component ensures your equipment remains compliant with manufacturer performance standards and avoids the risks associated with universal after-market alternatives.
Key Benefits- Factory-Matched Calibrations: Features a 160-180 degree operating range to maintain strict adherence to original equipment specifications.
- Automated System Recovery: The automatic reset capability eliminates the need for manual intervention after temporary temperature spikes.
- Broad ICP Compatibility: Direct fit for numerous residential furnace models across the Carrier family of brands, including Bryant and Payne.
- Robust Construction: Built to withstand high-cycle thermal stress within the furnace plenum for long-term reliability.
What causes a Carrier 338096-701 to trip repeatedly?
Frequent tripping is often a symptom of restricted airflow, typically caused by a dirty air filter, blocked return vents, or a failing blower motor. If the switch opens at 180°F and closes at 160°F accurately but the furnace continues to cycle on limit, inspect the heat exchanger and ductwork for obstructions.
Can I use a universal limit switch instead of the 338096-701?
While universal parts exist, using a genuine Carrier OEM part ensures the mounting footprint and temperature tolerances exactly match the original safety design of the furnace. This is critical for preventing premature failures and ensuring the switch reacts correctly to overheating.
Does this switch include the mounting gasket?
Yes, this assembly typically includes the industrial-grade gasket required to maintain a proper seal against the furnace cabinet, preventing air leaks and ensuring accurate sensing of the internal temperature.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
Carrier 338096-701 Limit Switch
Ensure critical safety and operational reliability in heating systems with the Carrier 338096-701 Limit Switch. This genuine OEM replacement part is engineered for precision temperature monitoring, serving as a primary high-limit safety cut-out for compatible Carrier, Bryant, and Payne furnaces. Designed with an automatic reset function, the switch features a calibrated thermal response that opens the electrical circuit when internal plenum temperatures reach 180°F (82°C) and automatically closes to restore operation once the system cools to 160°F (71°C). This L180-20F limit switch prevents heat exchanger damage and hazardous overheating conditions, making it a vital component for maintaining HVAC system safety. Technical specifications include a SPDT contact configuration and an electrical rating optimized for 24V control circuits. Replacing a faulty or tripped furnace limit switch with a factory-authorized component ensures your equipment remains compliant with manufacturer performance standards and avoids the risks associated with universal after-market alternatives.
Key Benefits- Factory-Matched Calibrations: Features a 160-180 degree operating range to maintain strict adherence to original equipment specifications.
- Automated System Recovery: The automatic reset capability eliminates the need for manual intervention after temporary temperature spikes.
- Broad ICP Compatibility: Direct fit for numerous residential furnace models across the Carrier family of brands, including Bryant and Payne.
- Robust Construction: Built to withstand high-cycle thermal stress within the furnace plenum for long-term reliability.
What causes a Carrier 338096-701 to trip repeatedly?
Frequent tripping is often a symptom of restricted airflow, typically caused by a dirty air filter, blocked return vents, or a failing blower motor. If the switch opens at 180°F and closes at 160°F accurately but the furnace continues to cycle on limit, inspect the heat exchanger and ductwork for obstructions.
Can I use a universal limit switch instead of the 338096-701?
While universal parts exist, using a genuine Carrier OEM part ensures the mounting footprint and temperature tolerances exactly match the original safety design of the furnace. This is critical for preventing premature failures and ensuring the switch reacts correctly to overheating.
Does this switch include the mounting gasket?
Yes, this assembly typically includes the industrial-grade gasket required to maintain a proper seal against the furnace cabinet, preventing air leaks and ensuring accurate sensing of the internal temperature.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
