Beckett Igniter 752801U Relay
The Beckett 752801U DPDT Relay is a specialized 120V HVAC replacement relay designed for reliable load switching in Beckett oil burner platforms and commercial heating equipment. This Double Pole Double Throw coil configuration allows for simultaneous control of two separate circuits, making it an essential component for managing complex burner sequences or auxiliary blower operations. Engineered for high-amperage switching, the 752801U provides stable contact performance under heavy inductive loads, ensuring consistent burner ignition cycles and system reliability. For field technicians, this Beckett burner igniter relay offers a direct-fit solution that minimizes diagnostic time when troubleshooting intermittent power delivery to the primary control or motor circuits.
- Enhanced Switching Versatility: The DPDT design manages dual independent circuits with a single 120VAC signal, reducing the need for multiple control relays.
- Industrial-Grade Contacts: Built to withstand high-frequency cycling without significant pitting or carbon buildup, extending the service life of the control assembly.
- Standardized Mounting: Designed for seamless integration within Beckett burner housings and standard NEMA enclosures, facilitating rapid field replacement.
- Consistent Load Handling: Maintains low contact resistance to prevent voltage drops across the relay coil during peak demand periods.
Common Technical Questions
Is the 752801U compatible with 24V control circuits?
No, this specific model is designed for a 120V AC input signal. Using a 24V signal will fail to energize the coil properly and could lead to contact chatter or complete failure.
Can this relay be used for both ignition and blower motor control?
Yes, the DPDT architecture allows one set of contacts to handle the oil burner igniter while the second set manages a secondary load, provided total amperage remains within the manufacturer’s specifications.
What are the symptoms of a failing Beckett relay?
Technicians often encounter humming from the coil, visible arcing across the points, or an open circuit reading between terminals even when the coil is energized.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
