Bard HVAC 5151-062BX Fan Blade
The Bard HVAC 5151-062BX Fan Blade is a critical condenser fan replacement designed for high-static pressure applications in Bard wall-mount units. This 22-inch, 3-blade component features a 1/2-inch bore and a 24-degree pitch, engineered to maintain optimal CFM output across the condenser coil. Precision-balanced to reduce vibration and bearing wear on the condenser motor, this blade ensures efficient heat dissipation in demanding commercial and industrial environments. Fabricated from heavy-duty aluminum with a reinforced steel hub, it resists corrosion and structural fatigue under high-torque startups. When diagnosing HVAC head pressure issues or excessive mechanical noise, verifying the blade pitch and hub alignment is essential. This OEM-spec fan blade serves as a direct drop-in for Bard 5151-062 series components, restoring factory-standard airflow velocity and ensuring the refrigeration cycle operates within designed pressure parameters for long-term system reliability in the field.
Key Benefits
- OEM Compatibility: Precision-engineered for a direct fit in Bard wall-mount HVAC systems, ensuring no modifications are required during field installation.
- Enhanced Durability: Constructed with high-grade aluminum blades and a secure steel hub to withstand outdoor condenser environmental exposure.
- System Efficiency: Maintains calibrated airflow velocity to prevent compressor overheating and high-pressure trips.
- Balanced Performance: Factory-balanced design minimizes shaft runout, extending the service life of the fan motor bearings.
Common Questions
How do I verify the pitch of the Bard 5151-062BX?
This blade is specified at a 24-degree pitch. Using a pitch gauge during inspection ensures the blade will move the required volume of air to satisfy the condenser coil heat transfer requirements.
Will this fan blade fit a 5/8-inch motor shaft?
No, the 5151-062BX is designed specifically for a 1/2-inch diameter shaft. Always check the motor nameplate or shaft diameter with a caliper before installation to ensure a secure press-fit.
What causes a condenser fan blade to fail prematurely?
Failures are typically caused by motor bearing wear leading to vibration, or debris strikes. Replacing a damaged blade immediately is vital to prevent catastrophic failure of the fan motor or damage to the coil fins.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
